Help CenterLug Type Soft Seat Butterfly Valve
US$ 7 - 4,000
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Butterfly
Pressure:
Medium Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
China main ports
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Wafer Type Butterfly Valve With Rubber SeatUS$ 10 - 40,000MOQ: 10 Pieces -
BS5163 Resilient Seated NRS Gate ValveUS$ 50 - 1,000MOQ: 10 Pieces
-
Standard Silencing Check ValveUS$ 35 - 2,000MOQ: 10 Pieces
-
ANSI 125/150 Resilient Seated NRS Gate ValveUS$ 50 - 1,000MOQ: 10 Pieces
-
BS5163 Rising Stem Gate ValveUS$ 50 - 1,000MOQ: 10 Pieces
Standard or Nonstandard
Standard
Structure
Butterfly
Pressure
Medium Pressure
Power
Manual
Material
Casting
Temperature of Media
Medium Temperature
Media
Water
Port Size
DN50-1200mm
Place of Origin
Shanxi, China
Brand Name
Allwin
Specifications
lug handle lever butterfly valve1.material: ductile iron/cast iron
2.standard:DIN/BS/ANSI
3.PN10/16/25
4.DN50-1200mm
lug type butterfly valve made in China
Specification
Standard:
| design standard | DIN3354 EN593 |
| top flange | ISO5211 |
| flange | DIN2501 |
| face to face | ISO5752-2 series 20 |
| test standard | DIN3230 |
Material List:
| No. | name | material |
| 1 | hand wheel | cast iron |
| 2 | screw | carbon steel |
| 3 | indicator | carbon steel |
| 4 | body | cast iron |
| 5 | stem | steel/ss416 |
| 6 | O ring | NBR |
| 7 | pin | steel |
| 8 | disc | ductile iron |
temperature: -25~120°C
dimensions:
large sizes can also be supplied.
Power: Manual,pheumatic,etc.
Painting: epoxy coating or as per your requirements
Color: blue,red,black or as per your requirements
Applicable Medium: water, sewage, sea water, air, medicine, oil, acid,etc.
If you are intrested in our products, please contact me at any time.
