Specifications
Circular vibrating screen1.Steady vibration
2.Large capacity
3.High Screening efficiency
4.CE,ISO certification
Vibration Sieve for Stone Crushing Plant
Introduction of Vibration Sieve
The vibrating sieve moves round with multi-layers and high efficiency. It can screen materials into multiple levels products according to different sizes. The Vibrating Sieve Machine is widely used for grading and screening in fields of mining, building material, transportation, energy,chemical industry, etc.
Advantages of Vibration Sieve
1. Long flowing line and various screening specifications.
2. Using the eccentric blocks to generate strong vibrating force.
3. Screen cross-beam and box are connected by strong belts, simple structure, convenient in maintenance.
4. Small amplitude, high frequency, large-inclination structure, high efficiency, large capacity, long service life, low power consumption and noise.
Parameters of Vibration Sieve
Type | layer | area (m2) | Sieve opening (mm) | Max. feeding size (mm) | Handling capacity (t/h) | Vibrating frequency (r/min) | power (kw) | Overall dimension (m) | weight (t) |
2YK1020 | 2 | 2.0 | 3-30 | 100 | 5-37 | 900 | 5.5 | 2.2*1.8*1.1 | 1.5 |
2YK1230 | 2 | 3.2 | 3-50 | 200 | 7.5-78 | 800-970 | 5.5 | 3.1×2.1×2.2 | 2.3 |
3YK1237 | 3 | 3.9 | 3-50 | 200 | 9-93 | 800-970 | 11 | 3.9×2.3×2.7 | 4 |
3YK1545 | 3 | 6 | 5-50 | 400 | 22-150 | 800-970 | 15 | 5.7×3×3.8 | 5.8 |
3YK1548 | 2 | 6.4 | 5-50 | 400 | 22.5-162 | 800-970 | 18 | 5.7×2.5×3.4 | 5.8 |
3YK1848 | 3 | 7.7 | 5-80 | 400 | 32-275 | 800-970 | 18 | 5×3.1×3.5 | 6.6 |
3YK1860 | 3 | 8.7 | 3-100 | 400 | 65-586 | 800-970 | 22-30 | 6.0×1.8×3.6 | 8.6 |
3YK2154 | 3 | 10.2 | 5-100 | 400 | 37.5-405 | 750-970 | 22 | 5.6×3.6×3.9 | 11 |
3YK2160 | 3 | 12.6 | 5-100 | 400 | 50-475 | 970 | 30 | 6.4×3.8×4.2 | 10 |
