Specifications
Applicate for dryer of paper making,especially for writing paper and printing paper etc.
Product picture
Technical data
| Name | BGW20604 |
| Material&Diameter |
Warp:polyester monofilament yarn(0.38mmx0.58mm) |
|
Weft:polyester monofilament yarn(0.60mm) | |
| Weight(g/m2) | 760 |
| Thickness(mm) | 1.42 |
| Density(counts/cm) | Warp:20.4 |
| Weft:7 | |
| Tensile strength(N/5X20cm) | Warp:5889.25 |
| Weft:4815 | |
| Elogation(%) | 22.6 |
| 34.2 | |
| Air permeability(CFM) | 698 |
Where to use?
Applicable for dryer of paper making.
We have following types of polyester dryer screen, include
BGW20604;BGW22608;BGW22708;GW22503;GW22504;LXW6035;LXW6850;LXW8080 and LXW9090.
our customer can select different types according to their request.
Advantage
1.Our polyester flat dryer screen is made by red flat polyester wires, it can increase the contact surface of our screen and the paper,so it will promote the heat transfer. when steam flow through our screen, it will decrease the probability of steam condensation, and improve the drying pared with the dryer screen made by roundness yarn, the wire marks is less in processing.
2.Our polyester flat dryer screen use the hydrolysis resistance monofilament wires, it can prominent enhance our screen's service life and increase our customer's economic effectiveness.
3.We make self pin joint for our polyester dryer screen, it's easy to install in all kinds of paper making production line, we also do resin edge reinforcement for our dryer screen, so the edge of our dryer screen is more strong.
Processing
Warping--Buckling--Weaving--Once heat set--Twice heat set--Edge reinforcement--Packing--Finish
Treatment
We make self pin joint and resin edge reinforcement for our polyester red flat dryer screen.
Inspection
We use air permeability test apparatus for air permeability testing, and breaking force test apparatus is use for tensile strength testing.
Packing
We have three types of packing, poly bag; wooden box and carton, our customers can select either one according to their request.
Do you need a price? if yes,please tell us these information as below:
1.Your detailed technical requirement.
2.Your usage or application of our products.
3.Your width and length,detailed measurement.
4.Terms of shipment.
5.The packing you need for shipping.
6.Which joint you want.
7.Do you need any treatment.
Any questions, pls feel free to contact with us.
