Specifications
1. 8-12meters reading distance2. EPC G2 prootol communication
3. 12dbi gain
4. 865-868mhz(customized optional)
ISO18000-6C 12dbi long reading distance UHF RFID antenna
Features:
1. This antenna gain is 12 dBi, with option for multipolarization
2. Working frequency is between865-868MHz; 902-928 MHz (can be customized)
3. With N connector or can be customized, lightning protection and DC ground;
4. IP67 IP rating design, adapt to work around the clock
Model |
VA-912 |
|
| ||
Performance Index | ||
Frequency |
865-868MHz; 902-928 MHz (can be customized) |
|
Input Impedance |
50 Ohm load |
|
Antenna connector |
N female antennas connector or can be customized. |
|
Gain-dBi |
12dBi |
|
VSWR |
≤1.3 |
|
Polarization |
Linear polarization or circular polarization |
|
Bandwidth |
26MHZ |
|
Front to Back Ratio -db |
≥18 |
|
Vertical 3.0dB Beam width-° |
35 |
|
Horizontal3.0Db Beam width-° |
36 |
|
Dimension |
450*450*40mm |
|
IP rating |
IP 65 |
|
Weight |
1.8kg |
|
Shell Material |
ABS plastic |
|
Why choose us:
Vanch Intelligent Technology Co.,Ltd. was established in 2005, one of the earliest UHF RFID products manufacture and application solutions supplier in China.VANCH products were widely used in City Smart transportation, Electric power system, asset and logistics management, the world's top 500 enterprises, government and military and other fields.
As High-tech enterprise and software development &Design company, Vanch has a number of patents and copyright of software and hardware. RFID products passed CE certification and FCC, sold very well in Europe and America market.
Membership of RFID Enterprise Alliance, RFID Standards Association and Internet of Things Association.
