Shop VIP customer tracking management with RFID UHF Tag Reader
- 1000 Set / Sets per Month
- Shenzhen
- Credit Card
You May Like
-
POE long range rfid reader for ETC with WIFI 3G GPS
-
uhf rfid handheld reader with 4.0 andoid system
-
portal UHF RFID bluetooth reader for asset tracking system
-
UHF RFID antenna reader for car parking lot
-
portal UHF RFID bluetooth reader 865 to 960mhz with android APP
-
EPC Class1 Gen2 rfid android handheld reader for jewelry inventory
Supplier's Choice
Product Details
| Place of Origin | Guangdong, China | Brand Name | VANCH | |
| Model Number | VF-747 |
Product Description
Shop VIP customer tracking management with UHF RFID Tag Reader
Overview:
This high perfornance fixed reader adopt Impinj RFID reader chip, which is R2000 serials. support high density reading, able to read 100 pcs tags above at a time, time used only is 5 seconds.it is extensively applied to retail, library and warehouse management.
Features:
1, more than 400 pcs tags reading simultaneously at a time.
2, more than 6 meter reading distance
3, comply with EPC G2 protocol
Parameters:
Model | VF-747 |
Dimension | 220(L)*230(W)*53(H)mm |
Weight | 1.5KG |
Operating Temp | -10°C to 55°C |
Storage Temp | -20°C to 80°C |
Humidity | 10% to 95% |
Non-condensing Enclosure | IP-40 |
Reader chip | Indy R2000 |
Frequency Range | 902-928MHz,865-868MHz or Customized |
Operation Mode | FHSS or fixed frequency (set by software) |
Work Mode | Command, Auto |
RF power control | 20-30dBm |
Protocol | EPC Class 1 Gen 2 |
Communication Interface | RS232/RS485/ TCP/IP(RJ45) |
Power supply | External 110-220V AC,DC +9V 3A Power adapter |
Antenna Connection | 4 Antenna SMA(female) connector |
Reading Clue | Buzzer and LED |
Reade Range | Depend on Antenna Gain and Length of RF Cable Connect 9dBi Antenna and 3m standard cable, the reading distance is about 6-8m |
