Shop VIP customer tracking management with UHF RFID Tag Reader
Overview:
This high perfornance fixed reader adopt Impinj RFID reader chip, which is R2000 serials. support high density reading, able to read 100 pcs tags above at a time, time used only is 5 seconds.it is extensively applied to retail, library and warehouse management.
Features:
1, more than 400 pcs tags reading simultaneously at a time.
2, more than 6 meter reading distance
3, comply with EPC G2 protocol
Parameters:
Model |
VF-747 |
Dimension |
220(L)*230(W)*53(H)mm |
Weight |
1.5KG |
Operating Temp |
-10°C to 55°C |
Storage Temp |
-20°C to 80°C |
Humidity |
10% to 95% |
Non-condensing Enclosure |
IP-40 |
Reader chip |
Indy R2000 |
Frequency Range |
902-928MHz,865-868MHz or Customized |
Operation Mode |
FHSS or fixed frequency (set by software) |
Work Mode |
Command, Auto |
RF power control |
20-30dBm |
Protocol |
EPC Class 1 Gen 2 |
Communication Interface |
RS232/RS485/ TCP/IP(RJ45) |
Power supply |
External 110-220V AC,DC +9V 3A Power adapter |
Antenna Connection |
4 Antenna SMA(female) connector |
Reading Clue |
Buzzer and LED |
Reade Range |
Depend on Antenna Gain and Length of RF Cable Connect 9dBi Antenna and 3m standard cable, the reading distance is about 6-8m |
