Mini Uhf Rfid Reader

Name: Mini Uhf Rfid Reader
Brand: VANCH
SKU: 101692047
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

VANCH

Model Number:

VM-5GC

Shenzhen Vanch Intelligent Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name VANCH

Model Number VM-5GC

mini uhf rfid reader

Product Description

Brief introduction

Integrated antenna character

1. Be sensitive and stable to the tags identify.

2. Stable reading distance 6-7 meters.

3. Multi-tags identify, >50pcs tags.

4. Reading distance speed, >50pcs/sec.

Solve the exothermic problem completely.

1. No need for connecting any other outer radiating device. It can work without exothermic reaction in the normal indoor temperature.

2. Sustain electricity<800mA @ 3.5V (30 dBm Output). Pulse peak current<1200mA.

Outstanding stability:

1. 24 hours x 365days work normally.

2. Appearance little influenced by cover, electromagnetic environment etc.

3. Wide temperature design and the temperature drift coefficient.

Good consistency:

1. The good design in consistency.

2. Choose the top level components to keep each parameters stable and consistence.

Brief and high efficient interface of hardware and software.

1. Peripheral circuit is very easy. The signal power, no need for extra connecting tantalum capacitor.

Installation method: support5pin WAFER installation.

Model No.	VM-5GC

Electrical parameters
Working Voltage	DC 3.5V – 5 V
PCB size	Pcb size:7070mm , Ceramic antenna size:6060mm Overall height:10mm
Standby current	<80mA (EN pin high level)
Sleeping current	<100uA (EN pin low level)
Operation current	180mA @ 3.5V (26 dBm Output,25°C). 110mA @ 3.5V (18 dBm Output,25°C).
Operating time	<100mS.
Operation temp.	- 20 °C - + 70 °C
Storage temp.	- 20 °C - + 85 °C
Working humidity	< 95% ( + 25 °C)
Protocol	EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C
Frequency	840-960MHZ
Working area support	US, Canada and other regions following U.S. FCC Europe and other regions following ETSI EN 302 208 Mainland China;Japan;Korea;Malaysia;Taiwan
Output power	18-26 dBm
Read/write	Read: 450-600cm;write: 10-50cm(adjusted)
Output power accuracy	+/- 1dB
Output power flatness	+/- 0.2dB
Receive sensitivity	< -70dBm
Store tag peak speed	> 50pcs/sec
Tags storage capacity	200pcs tags @ 96 bit EPC
Tags RSSI	support
Communication interface	TTL Uart interface
Communication baud rate	115200 bps(default and recommend) 38400bps
Heat-dissipating method	Air cooling(no need for out install cooling fin)
