RFID-enabled Building-management Systems for Car Vehicle Access Control

Name: RFID-enabled Building-management Systems for Car Vehicle Access Control
Brand: VANCH
SKU: 101691663
Availability: InStock

US$ 280 - 350 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

VANCH

Model Number:

VI-88F

Shenzhen Vanch Intelligent Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name VANCH

Model Number VI-88F

RFID-enabled building-management systems for car vehicle access control

Product Description

Introduction

l Based on independent intellectual property development, adapt reader to work with global frequency range.

l Application: logistics, access control, ETC, electronic security, manufacturing automation and etc.

Features

1. Support multi communication interfaces (LAN, RS232, RS485, Wiegand26/34);

2. RF output power 30dbm adjustable, support multi work modes (auto, command, triggering);

3. Reliable industry structure design, workable in varied severe environment.

Specification

Model#	VI-88F

Performance Index
Frequency range	902-928MHZ/865-868MHZ(or customized)
FM mode	FHSS or fixed frequency, set by the software
RF output	30dBm adjustable
Communication interface	LAN,RS232,RS485,Wiegand26/34
Communication rate	Serial port 9600~115200bps,RJ45 10Mbps
I/O interface	TTL
Power dissipation	average<15W
Application software	Provide with API SDK and VC, VB, Java application routines
Tag Operation Performance
Reading distance	5~18m equipped with 12dbi antenna(tag dependent)
Air interface	EPC global UHF ISO-18000-6C(EPC G2),ISO-18000-6B
Mechanical and Electrical Performance
Dimension	445(L)445 (W)70(H)mm
Power supply	Equipped with power convertor 220V AC input, +9V/3A DC output
Weight	5.2 KG
Humidity	5% to 95%, non-condensing
Protection grade	IEC IP 65
Operation temperature	-20 ºC to +60 ºC
Storage temperature	-40°C to 80°C
