EPC Class1 Gen2/ISO 18000-6C rfid reader handheld barcode scanner with 7meters
Introduction
l Based on independent intellectual property development, adapt reader to work with global frequency range.
l Application: warehousing and logistics management, assets inventory, production automation management and other data acquisition system.
Features
1. Support kinds of different modules optional, adapt to users’ different requirement;
2. Support EPC Class1 Gen2 / ISO18000-6C;
3. Output power can be adjustable by software,10~28dBm,1dBm step by step;
4. Read distance up to 7 meters(96mm*15mm tag);
5. Integration with Wifi 802.11b/g;
6. Ergonomics design handle, easy to handhold, relieve user’s feeling of fatigue to operate;
7. Continuous working time up to 4 hours, standby time about 20 days;
8. Industrial structure with high reliable design, meets harsh work environment requir
Specification
Specification |
|
performance & physical parameter | |
Protocol |
EPC Class1 Gen2/ISO18000-6C |
CPU |
High speed ARM platform,main frequency 450MHZ |
OS |
Android system 4.2 |
RAM |
2G |
Memory card |
2G Micro SD(standard configuration),support 32G at max. |
Barcode module options | |
1D module |
Symbol SE955 |
2D module |
Honeywell 5180 (optional) |
WIFI |
WLAN 802.11 b/g (standard configuration) |
Extend module |
4G |
Communication interface |
USB Slave |
Audio |
Typhoon, support multi-media function |
Dimension |
183mm* 81mm*146mm |
Weight |
703g(excluding charging base) |
Key |
27 keys |
Display & physical parameter | |
Screen |
5.0 inch TFT LCD(240*320),resistive touch screen, backlight adjustable |
Battery |
Rechargeable lithium polymer battery(3500mAh @ 7.4V ) |
Operation temperature |
-20° C~+50° C |
Storage temperature |
-30° C~+70° C |
Humidity |
5%~95% non-condensing(25°C) |
Accessories |
9V/1A charging base,USB cable |
Frequency parameter | |
US |
902 ~928MHz |
CN |
920 ~ 925MHz |
EU |
865 ~ 868MHz,other standard can be customized |
Read distance |
7 meters at max.(tag dependent) |
Write distance |
3 meters at max.(tag dependent) |
