R2000uhf rfid reader for Airline baggage transport management
What is “fixed reader” VF-747 made from?
1, Its Shell adopt high strength die-casting aluminum, highlighting the product quality
2, Its RF chip adopt the strongest-performance IMPINJ reader chip IndyR2000 with the best Intensive reader mode,the maximum read speed and optimum read ranges.
What project will “fixed reader” VF-747 be able to implement?
It can be qualified with many projects like: logistics supply chain, fixed asset management and library, warehouse management and archive management etc.
What is its main feature?
1, Adopt Impinj UHF reader chip and TI ARM embedded processing chips
2, Meet the EPC global UHF Class1 Gen2 / ISO 18000-6C / ISO18000-6B electronic tag standard
3, Operation frequency is between 860-868MHZ / 902- 928MHZ (can be adjusted according to different countries or regions)
4, Standard Interface: RS232, RS485 and TCP / IP network communication; Option: WIFI, GPRS, POE
5, Output power reach 32dbm, it is adjustable. Support active mode, command mode and trigger mode.
6, Reading buzzer and LED status indication; support online upgrade for hardware by communication port.
7, Reader supply multi I/O input output connectors, convenient for device to integrate and application
Quick View:
Performance Index | |
Frequency range |
860-868MHZ,902-928MHZ(can be customized) |
Frequency modulation |
FHSS or fixed-frequency, can be set by software |
RF output |
+10.0 to +32.5 dBm; 50 ohm load. |
The number of antennas |
1 TNC antenna connector; 2 TNC antenna connector; 4 TNC antenna connectors for selections |
Communication interface |
10M/100MAdaptive Ethernet,RS232,RS485,Wiegand26/34 interface |
Communication rate |
Serial rate 9600~115200bps,RJ45 is 10Mbps |
Secure firmware upgrade |
The upgrade mechanism can be extended |
input / output (GPIO) |
2 inputs, 1 output |
Certifications |
CE/FCC |
Application software |
Supply API SDK and VC and VB, Delphi application routines |
Tag Operation Performance | |
Reading distance |
8dbi Antenna configuration, typical read range: 3 to 25 m (depends on tag) |
Protocol |
EPC global UHF Class 1 Gen 2 / ISO 18000-6C/ ISO18000-6B |
Maximum receiver sensitivity |
-82 dBm; Maximum return loss: 10 DBm |
Mechanical electrical performance | |
Dimension |
200 (L) * 200 (W) * 35 (H) mm |
Power |
With 220V AC input, the output of +12 V/3A DC power converter |
Weight |
1.1KG |
Humidity |
5% to 95%, Non-condensing |
IP rating |
IEC IP51 |
Operating Temp. |
-20 ºC to +60 ºC |
Storage Temp. |
-40°C to 80°C |
