XCMG 8t Crawler Excavator XE85C

Name: XCMG 8t Crawler Excavator XE85C
Brand: XCMG
SKU: 101672337
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

XCMG

Model Number:

XE85C

Condition:

New

Jiangsu Sinma Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Brand Name XCMG

Model Number XE85C

Condition New

Moving Type Crawler Excavator

Operating Weight 7700/8100kg

Bucket capacity 0.16-0.34m³

Maximum Digging Height 7165

Maximum Digging Depth 4130

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

mini excavator

Model		Unit	XE85C
Operating weight		kg	7700/8100
Standard bucket capacity		m³	0.16-0.34
	Model Engine Model	/	4JG1TPC
	Direct injection	/	√
	Four strokes	/	√
	Water cooling	/	√
	Turbo charged	/	√
	Air to air intercooler	/	×
	No. of cylinders	/	4
	Rated power/speed	kw/rpm	53.8/2150
	Max. torque/speed	N.m	255/1800
	Displacement	L	3.059
Main performance	Travel speed	km/h	4.9/2.6
	Swing speed	r/min	11
	Max. gradeability	/	35°
	Ground pressure	kPa	34.6/36.4
	Max.Bucket digging force	kN	51.2
	Max.arm crowd force	kN	34.2
hydraulic system	Main pump	/	TOSHIBA
	Rate flow of main pump	L/min	1×198+21
	Max pressure of prime relief valve	MPa	27.4
	Max pressure of travel system	MPa	27.4
	Max pressure of swing system	MPa	20.6
	Max pressure of pilot system	MPa	3.9
Fuel	Fuel tank capacity	L	130
	Hydraulic tank capacity	L	115
	Engine lubrication	L	9.7
Dimension	A: Overall length	mm	6144
	B: Overall width	mm	2332
	C: Overall height	mm	2712
	D: Overall width of upperstructure	mm	2250
	E: Track length	mm	2837
	F: Overall width of undercarriage	mm	2320
	G: Crawler width	mm	450
	H:Dozer black(width/height)	mm	2320×416
	I: Tumbler distance	mm	2180
	J: Crawler gauge	mm	1870
	K: Clearance under counter weight	mm	827
	L: Ground clearance	mm	428
	M: Min.tail swing radius	mm	1805
Working range	A: Max. digging height	mm	7165
	B: Max. dumping height	mm	5060
	C: Max. digging depth	mm	4130
	E: Max. vertical wall digging depth	mm	3500
	F: Max. digging reach	mm	6295
	G: Min. swing radius	mm	1800
	H:Max.dozer lifting height	mm	409
	I: Max.dozer cutting depth	mm	438
	Angle of arm deflection	Degree	/
