Help CenterHydraulic Marine Winch
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Sinma
Model Number:
SM-MW
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangsu, China
Brand Name
Sinma
Model Number
SM-MW
Power Source
Hydraulic
Application
Boat
Specifications
Various large capacity marine winch availableMarine Winch specifications:
1) Drive: Electric / hydraulic
2) Configuration: Single or double drum with / without warping end
3) Wire drum: Steel wire rope drum
4) Rated pull (1st layer): 3 to 30MT
5) Brake: Holding 1.5 times the rated pull (static, first layer)
6) Wire speed: Up to 20 m/min
7) Paint: As per your specifications
| Mooring Winch (FOR 4 / 6 / 8 / 10 Mooring Systems) | |||||
| Model No. | Drum Capacity (SWR) (mxmm) | Brake Holding (T) | Rate Pull (Txm/min) | Slack speed (Txm/min) | Power (Kw) |
| MW/SD-20/48 | 500Xφ28 | 48 | 20x10 | 3.5x45 | 60 |
| MW/SD-25/60 | 500Xφ 32 | 60 | 25x10 | 6.0x35 | 75 |
| 1000x φ32 | |||||
| MW/SD-32/76 | 1000x φ38 | 76 | 32x10 | 8.0x34 | 90 |
| MW/SD-40/96 | 1000x φ38 | 96 | 40x10 | 10.0x31 | 110 |
| 1200x φ44 | |||||
| MW/SD-50/120 | 1200x φ48 | 120 | 50x8 | 12.0x28 | 110 |
| MW/SD-60/140 | 1500x φ52 | 140 | 60x8 | 14.0x31 | 150 |
| MW/SD-75/180 | 1500x φ60 | 180 | 75x8 | 17.0x31 | 180 |
| MW/SD-85/200 | 1500x φ63 | 200 | 85x8 | 20.0x30 | 220 |
