Home > Lights & Lighting > Outdoor Lighting > Street Light > 1W-4000W 365-405nm High Power UV Power Led (CE&ROHS)

1W-4000W 365-405nm High Power UV Power Led (CE&ROHS)

1W-4000W 365-405nm High Power UV Power Led (CE&ROHS) thumbnail-1
1W-4000W 365-405nm High Power UV Power Led (CE&ROHS) photo-1
Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ledsmaster
Model Number:
UWA200W-1013
Contact Supplier Request Quote Chat Now
Ledsmaster Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ledsmaster
Model Number UWA200W-1013

Specifications

200W UV led
1. Factory price
2.CE&RoHs
3.5000hrs LED lifespan
4.1W-4000W UV Power LED

high power50W UV power led

365-375nm UV Power LED





Benefits of LED UV Curing Products

•     Rapid Cure - light instantaneously on with no warm up required

•     No heating of substrates - cold curing close up to cure head

•     One peak wavelength of output power (multiple peaks possible as required by process)

•     No fuming of cured material normally caused by excessive radiant power from conventional lamps

•     Safe operation - no UVB, no ozone, no bulb break, low voltage, no mercury

•     Predictable radiant output power with limited drop off with life

•     Variable power - ability to create a cure profile with time e.g. reduced stress curing

•     Even intensity of radiant power over curing area

•     Long life time> 50,000 hrs of LED on time (LEDs only need to be on when curing)

•     Minimal drop off in power over life

•     Small size and light weight of cure heads

•     Ability to create three dimensional flood areas for curing complex shape

Part Number Power Chip
number		 Emitted Power Wavelength

LS-HPECL40M1UV-365 1Watt 1W 100-200mW 365-375nm
LS-HPEGH38M5UV-365 5Watt 4x1W 400-800mW 365-375nm
LS-HPEGH38M10UV-365 10Watt 9x1W 1000-2000mW 365-375nm
LS-HPEGH38M20UV-365 20Watt 20x1W 2000-4000mW 365-375nm
LS-HPEGH38M30UV-365 30Watt 30x1W 3000-6000mW 365-375nm
LS-HPEGH38M50UV-365 50Watt 50x1W 5000-10000mW 365-375nm
LS-HPEGH38M80UV-365 80Watt 80x1W 8000-16000mW 365-375nm
LS-HPEGH38M100UV-365 100Watt 100x1W 10000-20000mW 365-375nm
LS-HPEJY45M200UV-365 200Watt 200x1W 20000-40000mW 365-375nm
LS-HPEJY45M300UV-365 300Watt 300x1W 30000-60000mW 365-375nm



Part Number UWA100W-1013 UWA200W-1013 UWA300W-1030 UWA600W-1030 IWA500W-1050 IW1000W-1050 IWA800W-1080 IWA1600W-1080 IWA1000W-101A IWA2000W-101A IWA3000W-201A IWA4000W-201A
UV LED Power 100W 200W 300W 600W 500W 1000W 800W 1600W 1000W 2000W 3000W 4000W
Dominent Wavelength 365-405nm 365-405nm 365-405nm 365-405nm 365-405nm 365-405nm 365-405nm 365-405nm 365-405nm 365-405nm 365-405nm 365-405nm
Pure UV Power 30W 60W 90W 180W 150W 300W 240W 480W 300W 600W 900W 1200W
Input Voltage 110/220V AC 110/220V AC 110/220V AC 110/220V AC 110/220V AC 110/220V AC 110/220V AC 110/220V AC 110/220V AC 110/220V AC 110/220V AC 110/220V AC
ON/OFF Speed to full Output <5mS <5mS <5mS <5mS <5mS <5mS <5mS <5mS <5mS <5mS <5mS <5mS
Output Angle 120 degree 120 degree 120 degree 120 degree 120 degree 120 degree 120 degree 120 degree 120 degree 120 degree 120 degree 120 degree
LED Work Voltage 30-40V DC 30-40V DC 30-40V DC 30-40V DC 30-40V DC 30-40V DC 30-40V DC 30-40V DC 30-40V DC 30-40V DC 30-40V DC 30-40V DC
LED Work Current 3.5A 7A 10.5A 21A 17.5A 35A 28A 56A 35A 70A 105A 210A
Life Time 50000 hours 50000 hours 50000 hours 50000 hours 50000 hours 50000 hours 50000 hours 50000 hours 50000 hours 50000 hours 50000 hours 50000 hours
LED Curing Window Area (WxL) 100x130mm 100x130mm 100x300mm 100x300mm 100x500mm 100x500mm 100x800 100x800 100x1000 100x1000 200x1000 200x1000
Suggest Install Height (mm) 5-200mm 5-200mm 5-200mm 5-200mm 5-200mm 5-200mm 5-200mm 5-200mm 5-200mm 5-200mm 5-200mm 5-200mm
Fixture Width (mm) 145 145 145 145 145 145 145 145 145 145 220.00 220.00
Fixture Length (mm) 139 139 315 315 525 525 840 840 1050 1050 1050 1050
Fixture Height (mm) 79 79 79 79 79 79 79 79 79 79 79 79

1W-4000W 365-405nm high power UV power led (CE&ROHS)1W-4000W 365-405nm high power UV power led (CE&ROHS)1W-4000W 365-405nm high power UV power led (CE&ROHS)1W-4000W 365-405nm high power UV power led (CE&ROHS)1W-4000W 365-405nm high power UV power led (CE&ROHS)
