VOIP HD Dome IP Camera GXV3601_HD
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Grandstream
Model Number:
GXV3601_HD
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
Grandstream
Model Number
GXV3601_HD
Type
Other, IP Camera
Specifications
1.Grandstream VOIP Dome IP Camera2.Integrated PoE, embedded analytics
3.SIP/VoIP for full duplex 2-way audio,real-time video
Features & Benefits
- High resolution 2 Megapixels CMOS sensor and premium lens to ensure high fidelity picture quality
- Support advanced real-time H.264 (with multi-streaming-rate) and Motion JPEG at 720P resolution, variable bit rate & frame rate, and video watermark
- Support sensor alarm input, replay output, USB, SD, integrated Power-over-Ethernet (802.3af), and 24MB pre-/post-even recording buffer
- Built-in high performance streaming server to allow 6+ simultaneous HD viewers
- Embedded video analytics, SIP/VoIP support for full duplex two-way audio as well as video streaming to mobile phones and vido phones
- Support e-PTZ function
- Support IE and Firefox for network preview
- Built-in high performance streaming server to allow up to 16 simultaneous D1 viewers or 25 CIF viewers
- Combine with GSurf software to support remote viewing, controlling and recording of up to 36 cameras from anywhere on the Internet or corporate network.
VOIP HD Dome IP Camera GXV3601_HD
The GXV3601_HD is a next generation High Definition (720P) IP camera of extraordinary power and innovation. It features cutting edge H.264, real-time video compression (720P resolution) with excellent image clarity, industry leading SIP/VoIP for full duplex 2-way audio and video streaming, integrated PoE, embedded analytics, large pre-/post-event recording buffer, and advanced security protection. It supports the most comprehensive peripheral interfaces for alarm control, local storage expansion, and wireless network connection. The GXV3601_HD can be managed with GSurf, Grandstream's FREE video management software.
Feature Specifications
| Video Compression | H.264, JPEG, Motion JPEG |
| Image Sensor | Aptina 2-Megapixel 1/3.2" CMOS sensor, 1,600H x 1,200V, with low noise levels and low-light sensitivity |
| Lens Type | 1/3”, 3.5-8mm, F1.4, Mega Manual-Iris, CS |
| Day & Night | No |
| Minimum Illumination (Lux) | 0.5 Lux at F1.2 |
| Sensibility | 1.0V/lux-sec (550nm) |
| Max Video Resolution | 1,600 x 1,200 |
| Max Frame Rate in Max Resolution | 20fps for 1,600x900, 25fps for 1,280x720, 30fps for 800x450 |
| Video Bit Rate | 32 Kbps – 4 Mbps, adjustable (8Mbps maximum) |
| Video Output | N/A |
| Audio Input | 3.5mm LINE-IN, built-in microphone |
| Audio Output | 3.5mm LINE-OUT |
| Alarm Input | Yes – 1, Normal Open |
| Alarm Output | Yes – 1, 125VAC/0.5A, 30VAC/2A |
| Audio Compression | G.711, G.726 |
| Serial Ports | RS485 |
| IRIS Control | Manual Iris |
| Embedded Analytics | Motion detection (up to 16 target areas), video loss alarm(pending) |
| Pre-/post-alarm Buffer | 24MB |
| Snapshots | Trigger upon events, send via email/FTP |
| Multi-streaming-rate for Preview & Recording | Yes |
| Security | Video watermark, HTTPS, Password |
| Network Port | 10M/100M auto-sensing, RJ45 |
| Network Protocol | TCP/UDP/IP, RTP/RTCP, RTSP, DHCP, PPPoE, DDNS, HTTP, HTTPS |
| Power over Ethernet (PoE) | Standard, IEEE 802.3af Class 3 |
| Peripheral Ports | SD 2.0, USB 2.0 |
| SIP/VoIP Support | Yes |
| Power | Output: 12VDC/1A; Input:100–240VAC, 50–60Hz |
