Specifications
1.24-port managed L3 gigabit Ethernet Switch2.Ideal Fast Ethernet solution for building converged networks
24-port L3 managed gigabit Ethernet Switch GS-4024
Introduction
Ethernet switch GS-4024 offers many advanced features that make it the preferred choice for real-routing enterprise networks. Advanced functionalities like QoS, ratelimiting, rule-based access control lists, multicasting support, wire-speed, high-performance IP routing and simplified management software (iStacking) all contribute to the excellent efficiency of network operations.
Key Benefits
Ideal for Multi-service Network Environment
Ethernet switch GS-4024 delivers fully dynamic wire-speed IP routing features like OSPFv2 and RIPv2 using a hardware-based IP routing engine, as well as sophisticated multilayer operating software that quickly and precisely transmits Layer-3 traffics without packet loss or latency. In addition to dynamic IP routing, this type supports DVMRP, IGMPv3 and MVR for most applications on today’s IP-based multimedia platforms. With this type, enterprises can easily employ applications such as IP TV, video conferencing and distant learning.
Intelligent QoS for Mission-critical Applications
With more and more applications integrated into IP-based networks, the network traffic flows become more and more complicated and diverse than ever. To assure the multi-service quality on a converged network, adopting advanced traffic control technologies to manage different type of traffic flows is critical and necessary to enterprises. This Series supports Intelligent QoS features to optimize network traffics. With supports to Class of Service (CoS) and Differentiated Services Code Point (DSCP), administrator can easily classify and perform traffic prioritization for business-critical applications such as VoIP and video conferencing. In addition, this Series ethernet switch provides advanced bandwidth control with granularity of 64 kbps and 8 hardware priority queues to bring better bandwidth administration to network operators.
Robust and High-Availability System Design
This Series ethernet switch supports the VRRP routing protocol for failover transmissions, while BPS, the second DC power source, protects the system from internal AC power supply failure. The IEEE 802.3ad Link aggregation reduces network downtime by providing more packet paths and bandwidth aggregation to critical paths. The Gigabit uplink not only gives superb transmission bandwidth, but also allows users to set up Gigabit aggregation to secure transmission on critical paths, while the IEEE 802.1w Rapid spanning tree (RSTP) allows immediate recovery from failed links by sending packets via a backup link path.
Specification
Operating Temperature 0°C ~ 45°C
Storage Temperature -25°C ~ 70°C
Operating Humidity 10% ~ 90%, (non-condensing)
Features
Standard Compliance
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100 Base-Tx Ethernet
IEEE 802.ab 1000 Base-T Ethernet
IEEE 802.3z
IEEE 802.3x flow control
IEEE 802.1D spanning tree protocol
IEEE 802.1w rapid spanning tree protocol
IEEE 802.1s multiple spanning tree protocol
IEEE 802.1p class of service, priority protocols
IEEE 802.1Q VLAN tagging
IEEE 802.1x port authentication
IEEE 802.3ad LACP aggregation
IEEE 802.1ad VLAN stacking
Certification
UL 60950-1
CSA 60950-1
EN 60950-1
IEC 60950-1
EU RoHS compliant
