HUAWEI Storage VTL6900 Date Protection
OceanStor VTL6900 is a brand new virtual tape library (VTL) product from Huawei. It provides users a rich set of cutting-edge,
reliable, and flexible data protection functions. The VTL6900 features a powerful emulation capability, which can virtualize all mainstream physical tape libraries and tape drives. It seamlessly integrates high-speed disk backup technologies with traditional tape backup policies, ensuring the smooth transition from tape-based to disk-based. Additionally, it provides users various value-added functions including data deduplication and remote replication, meeting users' data backup requirements while significantly narrowing the disk scale, implementing remote disaster recovery, and decreasing the requirement of network.
Leading Performance
- Supports a maximum of 2304 TB of raw capacity (with 1690 TB of available capacity) and 31 TB/hour of backup performance.
- Be able to emulate a maximum of 256 tape libraries, 2048 tape drives, and 500,000 tapes, and is compatible with mainstream tape libraries and tape drives.
- Supports mainstream backup software.
- Supports global deduplication, eliminating cross-site redundant data and decreasing the requirement of intranet.
Flexible Configuration
- Offers multiple architectures, namely the integrated, single-node, and multi-node architectures, for different application scenarios.
- Provides diverse deduplication modes, namely the inline deduplication, post process deduplication, and non-deduplication modes, to meet customers' different requirements.
- Supports NAS, OST, and VTL interface protocols for different backup scenarios.
- Supports the Host Backup technology, eliminating the necessity of deploying backup servers and reducing space consumption and power consumption.
- Supports the disk spin-down technology to automatically spin down idle disks, dramatically reducing overall power consumption.
Overall Reliability
- In the multi-node architecture, VTL engines support the active-active mode and SIR engines support the 2+1 cluster mode for overall system reliability.
- Uses dedicated dual-controller disk arrays on the back end for data access reliability.
- Introduces RAID 6 and hot spare disks for data storage security.
- Employs the 256-bit Advanced Encryption Standard (AES) algorithm to protect data security of physical tapes.
Easy Management
- Smoothly replace physical tape libraries or tape drives without changing existing backup software and backup policies.
- Supports centralized device management using the Integrated Storage Manager (ISM).
- Supports the global topological view to monitor any engine units.
- Supports device alerting by email, ensuring that maintenance personnel can be promptly notified of device alarms.
|
Integrated
|
Single-Node |
Multi-Node |
|||||
|
VTL6900-IS |
VTL6900-I |
VTL6900-AIO |
VTL6900-SOLO |
VTL 6900-HAS |
VTL6900-HA |
||
|
Hardware Features
| ||||||||
Disk Type |
2 TB/4 TB SATA |
4 TB NL-SAS |
4 TB NL-SAS |
|||||
Max. Disk Slots |
12 |
288 |
288 |
576 |
||||
Max. Backup Rate* |
2.34 TB/hour |
1.18 TB/hour |
9 TB/hour |
7.9 TB/hour |
31 TB/hour |
31 TB/hour |
||
Failover |
No |
No |
Yes and optional |
|||||
De-duplication Mode |
Inline or post process |
No |
Inline or post process |
No |
Inline or post process |
No |
||
Optional Functions |
IP remote replication, tape caching, tape encryption, Open Storage, Host Backup, and NDMP |
|||||||
Virtualizable Tape Library* |
ADIC, Quantum, HP, IBM, SONY CSM-200, StorageTek, and Spectra Logic |
|||||||
Virtualizable Tape Drive |
HP LTO-4 (compatible with the LTO-1/2/3), LTO-5; IBM LTO-4 (compatible with the LTO-1/2/3), LTO-5 Quantum SuperDLT1, SDLT320; SONY SDX-700C, SDZ-130; StorageTek T10000A, T10000B, 9840D |
|||||||
Supported Backup Software |
Symantec NetBackup, Backup Exec; CommVault Galaxy; EMC Networker; IBM TSM; BakBone NetVault; CA BrightStor Enterprise Backup Server; Atempo Time Navigator |
|||||||
|
Physical features
| ||||||||
Power supply |
Engine unit: AC, 90 V to 264 V, 47 Hz to 63 Hz |
|||||||
| Power consumption | Engine unit: < 630 W; Storage controller unit: < 650 W; Storage expansion unit: < 480 W | |||||||
| Dimensions (H x W x D) | Engine unit: 2 U, 86 mm x 446 mm x 585 mm; Storage controller unit: 2 U, 86 mm x 446 mm x 582 mm; |
|||||||
| Weight (in full configuration) | Engine unit: 32 kg; Storage controller unit: 42.48 kg; Storage expansion unit: 44.1 kg | |||||||
| Operating ambient temperature | 10°C to 35°C with an altitude less than 1800 meters;10°C to 30°C with an altitude from 1800 meters to 3000 meters | |||||||
| Operating ambient humidity | 20% RH to 80% RH | |||||||
* Backup performance is based on the formula 1 TB = 1,000,000 MB, the number of disks used in the max performance dual node configuration > 300, and the number of disks used in a single node configuration > 80.
* The maximum backup performance of no-deduplication is inline deduplication, Maximum backup performance of VTL HAS requires two sets of clusters.
* For the full list of virtualizable tape libraries, refer to the VTL6900 Compatibility List.
- Trade terms: FOB,CIF,CFR,etc
- Price Terms: L/C,D/P,T/T,Western Union,PAYPAL
- Payment Terms: T/T in advance
- MoQ: 1 pcs
- FOB Price:US $1 - 1,000 / Piece
- Port: Shanghai
- Lead time: Within 5 working days after receipt payment.
- Shipment: Express, Air, Sea
- Supply capability: 200 Piece/Pieces per Week
- Sample availability: Yes (not free)
- Package information: carton package with the original package
- We can provide detail documents and remote help for device installation and configuration.
- Warranty: 1 year. ( After the quality guarantee period began to charge appropriate maintenance service fee.)
- Our company promises goods enjoy full return due to quality problem since goods delivered within 7 days or 15 days , returned goods must keep original state and it’s accessories are complete.
- Please contact me for more detail information. Skype:Nathan.Liu2015
