Cisco Router Asr1001

Cisco Router Asr1001 thumbnail-1
Cisco Router Asr1001 photo-1
US$ 1 - 4,800 MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Wired
Function:
Firewall, QoS, VPN
Contact Supplier Request Quote Chat Now
Shanghai Chu Cheng Information Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Type Wired
Function Firewall, QoS, VPN
Certification CE,EMC
Brand Name CISCO
Model Number ASR1001

Specifications

1. LAN : 4 x SFP (mini-GBIC)
2. USB : 1 x 4 pin USB Type A


Product Description



The Cisco ASR 1001 Router offers a default system bandwidth of 2.5 Gbps upgradable to 5 Gbps with a software-activated upgrade license. It houses one shared port adapter (SPA) slot that supports single-height SPAs. It includes four built-in Gb Ethernet ports. The first IOS XE software release supporting ASR 1001 is Cisco IOS XE 3.2.0S.

The Cisco ASR 1001 Router also introduces the concept of integrated daughter cards (IDCs). Six models of the Cisco ASR 1001 Router are currently available:

  • ASR1001: without an IDC
  • ASR1001-2XOC3POS: with an IDC that provides two OC3 POS ports
  • ASR1001-4XT3: with an IDC that provides four T3 ports
  • ASR1001-4X1GE : with four 1-Gigabit Ethernet ports
  • ASR1001-HDD (160 GB): with a 160-GB hard disk drive
  • ASR1001-8XCHT1E1 : with eight channelized T1/E1 ports

The IDCs are not field-upgradable.

The ASR 1001 is ideal for:

  • High-end enterprise branches
  • Managed services, including VPN and firewall
  • WAN aggregation and secure WAN
  • Deep packet Inspection (DPI)
  • Route reflector
  • Low-end broadband aggregation (LNS)

Software Activation

Software activation is supported on the ASR 1001 for some licenses. These licenses enforce consolidated packages such as the software feature sets for K9 and non-K9 IP Base, Advanced IP Services, and Advanced Enterprise Services, as well as the performance upgrade from 2.5 Gbps (default) to 5 Gbps.cisco router asr1001cisco router asr1001cisco router asr1001

Genarel data



ManufacturerCisco
Manufacturer Part #cisco asr1001
Cost Central Item #11270932
Product DescriptionCisco ASR 1001 - Router
Device TypeRouter
Enclosure TypeDesktop - modular - 1U
PerformanceESP bandwidth : 2.5 Gbps
PowerAC 120/230 V ( 50/60 Hz )
Approximate Dimensions (WxDxH)17.3 in x 18.5 in x 1.7 in



Device TypeRouter
Enclosure TypeDesktop - modular - 1U
Connectivity TechnologyWired
PerformanceESP bandwidth : 2.5 Gbps
Compliant StandardsCISPR 24, EN55022, VCCI Class A ITE, EN55024, CISPR 22, EN50082-1, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A, FCC CFR47 Part 15, EN300-386, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1-03
Processor1 x Intel
RAM4 GB (installed) / 16 GB (max)



Expansion and power



InterfacesManagement : 1 x 10Base-T/100Base-TX - RJ-45
Management : 1 x console - RJ-45
Management : 1 x auxiliary - RJ-45
LAN : 4 x SFP (mini-GBIC)
USB : 1 x 4 pin USB Type A
Expansion Slots1 (total) / 1 (free) x expansion slot
Installed Modules Qty (Max)0 (installed) / 1 (max)
Power DeviceInternal power supply
Power RedundancyYes
Installed Qty2 (installed) / 2 (max)
Voltage RequiredAC 120/230 V ( 50/60 Hz )
