Home > Industrial Equipment & Components > Power & Generating Sets > Gasoline Generator > GX200 6.5hp 168f-1 170f CE Approved, Low Noise, Water Pump, Small Gasoline Engine for Thiland

GX200 6.5hp 168f-1 170f CE Approved, Low Noise, Water Pump, Small Gasoline Engine for Thiland

GX200 6.5hp 168f-1 170f CE Approved, Low Noise, Water Pump, Small Gasoline Engine for Thiland thumbnail-1
GX200 6.5hp 168f-1 170f CE Approved, Low Noise, Water Pump, Small Gasoline Engine for Thiland thumbnail-2
GX200 6.5hp 168f-1 170f CE Approved, Low Noise, Water Pump, Small Gasoline Engine for Thiland photo-1
GX200 6.5hp 168f-1 170f CE Approved, Low Noise, Water Pump, Small Gasoline Engine for Thiland photo-2
US$ 45 - 60 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
WK
Model Number:
GX200
Contact Supplier Request Quote Chat Now
Taizhou Wokun Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name WK
Model Number GX200
Output Type AC Single Phase
Speed 3000/ 3600rpm
Frequency 50/60 Hz
Rated Power 1.5/ 1.8/ 2.0/ 2.2/ 2.5/ 2.8/ 4.0/ 5.0/ 6.0kw kva
Rated Voltage 240/ 220/ 120/ 110 V
Rated Current 12V 8.3A
GX200 6.5hp 168f-1 170f CE approved, low noise, water pump, small gasoline engine for Thiland

GX200 6.5hp 168f-1 170f CE approved, low noise, water pump, small gasoline engine for Thiland







- Technical Data:

Power: from 5.5hp to 13hp



Engine Model GX160 GX200 GX270 GX340 GX390
Type OHV, Tilt, Single cylinder, 4-stroke, Forced air-cooled, gasoline engine
Max. Power(HP) 5.5HP/3600rpm 6.5HP/3600rpm 9HP/3600RPM 11HP/3600rpm 13HP/3600rpm
Displacement(cc) 163CC 196CC 270CC 338CC 389CC
Ignition Model Non-contact transistorized ignition (TCI)
Starting System Recoil start Recoil start Recoil start Recoil start Recoil start / Electric start
Fuel tank capacity 3.6L 3.6L 6L 6.5L 6.5L
Bore*Stroke(mm) 68*45mm 68*54mm 77*58mm 82*64mm 88*64mm
Net Weight(kg) 16 16.5 25 31 35
Dimension(mm)(L*W*H) 375x300x345mm 375x300x345mm 465x410x455 465x410x455 465x410x455
20GP' container 684PCS 684PCS 350PCS 350PCS 350PCS
40HQ' container 1638PCS 1638PCS 700PCS 700PCS 700PCS

Starting: recoil start, with electric start optional

Optional 1: normal or silver muffler

Optional 2: brown or color carton

Tell us your detail requirement, to recommend you the right one



 - Features
1. Economical, reliable and durable
2. Oil alert to shut down engine automatically when low oil is detected

3. Easy to strt, durable OHV, high quality

4. CE, SONCAP, ISO certification approved
5. One year or 500 hours warranty





- Factory Show

     - Raw Material

GX200 6.5hp 168f-1 170f CE approved, low noise, water pump, small gasoline engine for Thiland







- Assembly

GX200 6.5hp 168f-1 170f CE approved, low noise, water pump, small gasoline engine for ThilandGX200 6.5hp 168f-1 170f CE approved, low noise, water pump, small gasoline engine for Thiland





- Test

GX200 6.5hp 168f-1 170f CE approved, low noise, water pump, small gasoline engine for Thiland







- Packing

GX200 6.5hp 168f-1 170f CE approved, low noise, water pump, small gasoline engine for Thiland


- Loading:

GX200 6.5hp 168f-1 170f CE approved, low noise, water pump, small gasoline engine for Thiland





























- Certificate:

GX200 6.5hp 168f-1 170f CE approved, low noise, water pump, small gasoline engine for ThilandGX200 6.5hp 168f-1 170f CE approved, low noise, water pump, small gasoline engine for ThilandGX200 6.5hp 168f-1 170f CE approved, low noise, water pump, small gasoline engine for Thiland







- Sample Room

GX200 6.5hp 168f-1 170f CE approved, low noise, water pump, small gasoline engine for Thiland





- Customers

GX200 6.5hp 168f-1 170f CE approved, low noise, water pump, small gasoline engine for Thiland





5.5hp to 13hp gasoline engine

Professional generator manufactrurer with R&D capacity

Reliable quality, reasonable price, desirable service

Tell us your demand, provide what you want

Contact us now, let's make a deal.........
