LXQ Type 6 ~ 35 kv voltage neutral with harmonic elimination damper (L) harmonic elimination device
LXQ Type 6 ~ 35 kv voltage neutral with harmonic elimination damper (L) harmonic elimination device, is installed in 6 ~ 35 kv voltage transformer (hereinafter referred to as compression or P.T) Y0 a winding connection between neutral and to a nonlinear harmonic elimination. Used to eliminate or damping variable magnetic saturation caused by electromagnetic resonance overvoltage, this kind of resonance overvoltage will lead to an unstable system phase voltage;
Used to limit the single-phase grounding system disappears, the pressure becomes a winding circuit of flow, the flow will burn out PT or PT blown fuse;For when the single-phase grounding system can be a long time to protect
PT or make PT from damage.
LXQ type DC characteristic of harmonic elimination is similar to traditional RXQ type harmonic elimination device, but different structure design.L harmonic elimination of small size, light weight, fast heat dissipation, high mechanical strength, easy to install, no outside porcelain set of protection. It is after more than one thousand degrees high temperature sintering of multiple nonlinear damping component and harmonic elimination, series of bare surface structure through special processing, can the incarnation, winter heat.Although there is no outside porcelain jacket protection, still can be directly used in outdoor.
LXQ said bare without outside porcelain liner protection pressure changes of neutral with harmonic elimination damper.
Technical Parameters
Type No. |
DC Feature kV/mA |
Nonlinear coefficient A |
Heat capacity250mA/10min |
Size(mm) L * W * H |
Weight (kg) |
||
|
LXQ6~10KV
|
Universal |
1.45~1.65/15 |
0.40~0.50 |
through |
120×50×260 |
1.6 |
|
Weak insulation type |
1.38~1.42/15 |
0.40~0.50 |
through |
120×50×260 |
1.6 |
||
Plateau type |
1.48~1.52/15 |
0.40~0.50 |
through |
120×50×260 |
1.6 |
||
Subminiature |
1.45~1.65/15 |
0.30~0.40 |
V |
120×50×130 |
0.8 |
||
|
LXQ 35KV
|
Universal |
A |
4.00~4.2/42 |
0.40~0.45 |
through |
120×50×260 |
1.6 |
B |
>2.80~2.85/50 |
0.35~0.45 |
through |
120×50×260 |
1.6 |
||
Weak insulation type |
2.60~2.70/50 |
0.35~0.45 |
through |
120×50×260 |
1.6 |
||
Plateau type |
1.90~2.10//15 |
0.35~0.45 |
through |
120×50×260 |
1.6 |
||
Subminiature |
>2.80~2.85/50 |
0.30~0.40 |
through |
120×50×130 |
0.8 |
||
