High Voltage jacket , Insulating sheath
1.classification:
10KV fuse , transformer, Surge arrester
2. Electric power equipment insulation protection cover adopt silicon rubber mould pressing, high temperature materials have excellent electrical properties, ageing resistance, resistance to high and low temperature, can be used in any condition. Is transformer, lightning arrester, outdoor switch power equipment such as wiring must end with the insulation of the safety protective equipment, the product can effectively prevent the original bare power equipment end due to human contact, power, small animals or sundry lap, wet flash salt fog and chemical gas corrosion caused by the power outage, so as to avoid the resulting huge economic losses.
3. featuies
(1). Effectively prevent margin of animals and birds and other small animals or foreign body lap short circuit caused by the accident
(2) to prevent condensation flash flash flipping, flipping, filthy icicles sticky snow caused by electrical accident
(3). To prevent acid rain, salt fog and harmful chemical gases on corrosion of outlet and inlet line of transformer
(4). Avoid pedestrians by accident exposed the personal casualty caused by electric contact
(5). Shield can prevent criminals and metering device fully enclosed operation power
(6). Hooking structure, simple installation, can be repeated use
| Product Model | Rated voltage | Rated current(A) | Lightning impulse withstand voltage(peak)(kV) | P.F withslend voltage(virtual value) | Bending break load(N) | Permitted bending load(N) |
| 10/220~630 | 10 | 200~630 | 75 | 30 | 120 | 625 |
| 35/630~1600 | 35 | 630~1600 | 200 | 80 | 1250 | 625 |
| 66/630~1600 | 66 | 630~1600 | 325 | 147 | 1250 | 625 |
| 110/630~1600 | 110 | 630~1600 | 550 | 230 | 1250 | 625 |
1.Over 20 years of manufacturing experience with good quality & stable product performance.
2. Hossin provides full line of MV-HV electrical products, including drop-out fuse, disconnector, surge arrester, vacuum circuit breaker, fuse, load switch, insulator etc.
3. Quick feedback, Timely quotation, Fast delivery
4. Complete set of testing machine to ensure product quality.
5. Hossin can customize non-standard product as per client’s requirement.
6. Hossin sells pressing parts& pressing mould at low price.
7. Hossin offers electrical installation & commission service.
