Outdoor Vacuum Load Switch FZW32-12 FZW32-40.5
FZW32-12 (40.5) type outdoor high voltage isolating vacuum load switch is a new
type of load switch which is the integration of mature experience of domestic
existing load switch and advanced technology design of external. This load switch is
composed of isolating switch, vacuum interrupter and operating mechanism and
other parts. By using the principle of vacuum interrupter, with strong arcing ability,
reliable performance, long service life, small volume, no explosion danger, no
pollution etc advantage. The product can be used in transmission and distribution
system of electric power, metallurgy, mine, chemical industry and other departments
as control equipment, especially suitable for frequent operation place.
1. Ambient temperature: upper limit +40℃, lower limit -30℃;
Days difference does not exceed 32K;
2.Altitude: 1000m and the following areas;
3.Wind pressure: no more than 700Pa (corresponding to the wind speed 34m/s);
4.Air pollution level: IV class
5.Earthquake intensity: do not exceed 8 degree;
6.Ice thickness: no more than 10mm.
