Specifications
109A Acrylic laser cutting machine special for cut acrylic sheet design, machine use 3 axles servo and ball screw, linear guider109A Acrylic laser cutting machine
Model: 109A
Laser Power: 100W-150W
Worktable size: 1250x900mm
Application: Acrylic, MDF, PVC, cartoon, celebration card.
1. Characteristics
l Machine chooses high quality 150W DC excited CO2 laser tube or 100W UK GSI tube.
l Strict lathe bed heat treatment process and scientific machine tools assemble ensure
machine excellent performance and longevity.
l 3 axles servo drive system and ballscrew & guide rail transmission systemmake sure
the best cutting accuracy.
l Special optical path compensation technology and protection system ensure laser cutting kept
consistency in the whole working area.
l Special laser dedicated cooling system, effectively extending the life of laser working.
l Open can use, no start machine fare, low consumption
2. Paramerts
No. |
Name |
Specification |
1 |
Model |
109A |
2 |
Laser Source |
100W-150W GSI /Chinese |
3 |
Working Area |
1250mmx900mm |
4 |
Machine Structure |
Closed |
5 |
Optical System |
Flying-optics |
6 |
Control System |
Off-line Motion control card |
7 |
Driving System |
Imported servo driving system |
8 |
Transmission System |
Ball screw and Linear guide |
9 |
Acceptable File Format |
Dxf. Ai. |
10 |
Overall Dimension |
2250mm×1650mm×1400mm |
11 |
Weight |
800KG |
12 |
Power Supply |
220V/50HZ/20A |
