RH-B High-voltage Isolation Switch Disconnector Switch
US$ 220 - 588
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
hossin
Model Number:
RH-B-11KV RH-B-33KV
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
FN-24KV FN7-24KV 24KV Load Switch 24KV Load Break SwitchUS$ 500 - 1,000MOQ: 1 Furlong -
GN24-12 GN24 GN24-12C Indoor Disconnector Isolating SwitchUS$ 100 - 110MOQ: 1
-
33KV-40.5KV Outdoor High Voltage Disconnector Switch/Isolate SwitchUS$ 500 - 600MOQ: 1 Piece
-
24KV 20KV Outdoor High-voltage Isolation Switch Silicone RubberUS$ 13 - 250MOQ: 1 Set
-
HGW5 Type Outdoor High-Voltage Disconnector Switch Isolate SwitchUS$ 500 - 600MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
hossin
Model Number
RH-B-11KV RH-B-33KV
Max. Current
200A-400-630A
Max. Voltage
11KV 33KV
RH-B High-voltage isolation switch Disconnector Switch
Product Overviews
Outdoor AC Gang isolator switch 11kv/400A-33kv/600A used in 3 phase AC
50/60Hz power circuit, it is used as switching on and switching off at the
voltage with no load. It apply to IEC standard. IEC60964: 1996, IEC62271-102:
2002.
Working Conditions
Altitude:1000 to 3000m.
Ambient temperature:-30 celsius to +40celsius
The relative humidity of air:monthly humidity not more than 90%,daily humidity
not more than 95%.
Wind pressure:not more than 700Pa( wind speed is 34m/s).
Amplitude:earthquake degree 8
Environmental pollution degree:degree III
Specification
| Type | Rated voltage (KV) | Rated current (A) | 4s heat steady e.c.A | Shock voltage (A) |
Impulse withstand voltage (KV) |
Power-frequency withstand voltage(KV) |
| RH-B | 11 | 400 | 12500 | 31500 | 95 | 42 |
| RH-B | 33 | 600 | 12500 | 31500 | 195 | 80 |
Outline Drawing
