PP/HIPS/GPPS Sheet Extrusion&Thermoforming Online Machine

PP/HIPS/GPPS Sheet Extrusion&Thermoforming Online Machine thumbnail-1
PP/HIPS/GPPS Sheet Extrusion&Thermoforming Online Machine photo-1
US$ 2 - 3 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
FJL
Contact Supplier Request Quote Chat Now
Zhejiang Fuxinlong Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name FJL
Model Number FJL-660(2)
Certification CE

Specifications

FJL-660(2) Mono-layer PP/HIPS/GPPS Sheet Extrusion&Thermoforming Online Machine is our new products.

II. MAIN PARAMETERS:

  1. 1.       Processed Material: PP/HIPS/GPPS Granule or powder
  2. 2.       Max. output capacity of extruder: around 80Kg/hr
  3. 3.       Max. forming area: 650*320mm
  4. 4.       Max.forming depth: 120mm
  5. 5.       Running Speed of Thermoforming machine: 15-30 cycles/min

                  III.Configuration and specification:

  1. 1.       Main Extruder: one
    1. a.       Hard-tooth Gearbox: one    Model: 200

The body of the gearbox is made from cast steel. The teeth deal with grinding and peeling eventually, which provides different characteristics of damping, antifriction, low-noise, long using period etc.

  1. b.       Connection method of gear box and motor: Direct connection
  2. c.       The screw

Material: high quality nitrided steel-38CrMoAlA

Nitration depth: 0.4-0.7mm, hardness≥940HV, fragility is 2 grades.

  1. d.       Barrels

Material: high quality nitrided steel-38CrMoAlA

Nitration depth: 0.4-0.7mm, hardness≥940HV, fragility is 2 grades.

  1. e.       Heating zones: 4 zones
  2. f.        Total Heating Power: 19KW
  3. g.       Heaters: The electric heater is made of stainless steel. Every electric heater has a specially designed tunnel for heat radiating
  4. h.      Main motor power: 37KW, 6-gear, FC; rotary speed: 980r/min
  5. i.        AC motor with 37KW inverter control
  6. j.        Screw diameter: 80mm
  7. k.      L/D: 28:1
  8. l.        Movement motor of extruder: 750W
  9. m.    Screw Type Material Autoloader: one set



  1. 2.       Automatic Hydraulic Fast screen changer with double-sieve: one set
    1. a.       Its special internal structure provides a excellent seal effect
    2. b.       The parts of Screen Changer consisting the mould are made of alloy steel, which experienced heat treatment strictly.
    3. c.       Control Method: by hydraulic station
    4. d.       Motor Power: 2.2KW
    5. e.       Heating Zone: one
    6. f.        Total Heating Power: 6KW



  1. 3.       Die-Head
    1. a.       Material: super heat resistance alloy steel
    2. b.       Structure: T-shaped, Clothes bracket flow channel, polished inner mold surface.
    3. c.       The flows are plated chrome. And the flow surface is polished until it like mirror.
    4. d.       The outlets of the mould can be adjusted with the adjustable screws slightly.
    5. e.       There are 3 heating zones in the T-die
    6. f.        Heating power: 11KW
    7. g.       The heat means: heating inside by bar heaters
    8. h.      The effective width of the die head:900mm

 4.       Air cooling stand: one

  1. a.       Number of the transmission rollers: one pc
  2. b.       Diameter of the rollers: 180mm
  3. c.       Roller length: 780mm
  4. d.       Roller surface treatment: plated chrome and half-mirror polishing
  5. e.       Movement motor: 750W

 5.       Haul off unit: one

  1. a.       Haul off steel roller: two pcs

Diameter of the roller:75mm

Length of the roller: 880mm

Surface treatment: frosted

  1. b.       Motor: 3KW
  2. c.       AC motor with a 3KW inverter



  1. 6.       Online Two-Pillar Thermoformer Unit

Max. forming area: 650*320mm

Max. Draw depth: 120mm

Running speed: 15-30 Strokes/min

Cutting Arrangement: in-mold cutting

Material used: PP,HIPS,GPPS

Oil Pump Motor Power: 15KW

Forming Method: by air pressure with plug assisted

Motor Power of Rewinder: 180W
