Home > Manufacturing & Processing Machinery > Plastic Machinery > Plastic Extruder > FJL-660PC Plastic Sheet Extruder
FJL-660PC Plastic Sheet Extruder
US$ 23,000 - 25,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Sheet
Plastic Processed:
PP
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO PORT
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Application
Sheet
Plastic Processed
PP
Screw Design
Single-screw
Place of Origin
Zhejiang, China
Brand Name
FJL
Model Number
FJL-660PC
Specifications
FJL-660PC Plastic Sheet extruder for making PP/PS/PE sheet roll.
Samples of products:
Usage:
FJL-660PC Series Plastic Sheet Extruder is designed to pruduce monolayer PP/PS/PE plastic sheet ,which is used to make disposable water drinking cups,ice-cream cups,disposable cup/bowl for yoghurt,lids,dishes,plates and etc.
Features:
(1) the main parts, such as screw ,barrel, adopt superior 38CrMoAlA material, which is featured by high hardness,anticorrosive advantages.
(2) The special designed screw adopts big L/D Ratio to ensure the good plasticizing,stable extrusion and high output.
(3) Screen extruder:it is controlled by motor and its operation is very easy (we can also adopt hydraulic style fast screen exchange with double filters according to customers demand.
| Main Technical Parameter | ||||
| Moldel | FJL-660PC90 | FJL-660PC105 | FJL-660PC110 | FJL-660PC120 |
| Material Used | PP/PS/HIPS/PE | |||
| Sheet Width | ≤690mm | ≤690mm | ≤690mm | ≤690mm |
| Sheet Thickness | 0.3-2.0mm | 0.3-2.0mm | 0.3-2.0mm | 0.3-2.0mm |
| Layer | 1 | 1 | 1 | 1 |
| Extrusion Capacity | ≤150kg/h | ≤180kg/h | ≤200kg/h | ≤260kg/h |
| Screw Dia. | 90mm | 105mm | 110mm | 120mm |
| Roller Dia. | 350mm | 350mm | 350mm | 350mm |
| Motor Power | 37KW | 45KW | 55KW | 75KW |
| Overall Power | 90KW | 100KW | 110KW | 130KW |
| Overall Dimension | 10.5*1.8*2.2 | 10.5*1.8*2.2 | 11.5*1.8*2.2 | 12.0*2.0*2.2 |
| Weight | 6.0T | 6.5T | 7.0T | 7.5T |
| Power Supply | 380V/50HZ,Tri-phase,Four-wire | |||
