Help CenterFJL-700/1200ZK-B Hi-speed Plastic Blister Forming Machine
Related Products
-
FJL-700/1200ZK-B High-speed Automatic Plastic Egg Tray Making MachineUS$ 21,000 - 23,000MOQ: 1 Set -
FJL-700/1200ZK-B Plastic Egg Tray Making Machine/Vacuum Forming MachineUS$ 20,000 - 22,000MOQ: 1 Set
-
FJL-700/1200ZK-B Automatic Plastic Vacuum Forming MachineUS$ 20,000 - 22,000MOQ: 1 Set
-
FJL-700/1200ZK-B 2014 New Design Plastic Vacuum Forming Maching PriceUS$ 21,000 - 23,000MOQ: 1 Set
-
Automatic Plastic Blister MachineUS$ 24,300 - 33,500MOQ: 1 Set
Specifications
It's used for making various of containers1.PLC system
2.up+ down heating together
3.high output
Usage
This machine is suitable for producing disposable plastic fast-food containers, bowls, plates, food container , articles of daily use and etc .
I.Main Technical Parameter
| Model | FJL-700/1200 ZK-B |
| Approximate Forming Area | 700 x 1200 mm |
| Running speed | 3-12 moulds / min |
| Forming width | 510~ 740mm |
| Mode of cutting arrangement. | Off-mould. |
| Sheet thickness | 0.1 -1.2 mm |
| Material | PP,PS,PVC,PET |
| Max. Forming depth | Negative Mould ≤ 180 mm |
| Positive Mould ≤ 200mm | |
| Heating arrangement | Top + Down heating with IR Ceramic Heater |
| Total Heating Power | 35KW |
| Temperature Controller & Thermocouple. | PID , K-Type |
| Power supply | 380/220V ,50HZ , 3phases,4 wires |
| Dimensions | 7.8 X1.4 X 2.2 (m) |
| Weight | 3.2 T |
II.Major construction features
1. The machine adopts PLC control system to make the machine working more reliably.
2. The machine can achieve both of accuracy and stability during high-speed operations, .
3. Equipped with a unique divided temperature control system and a infrared ceramic heater
4. The major electronic devices and pneumatic components are manufactured abroad,
5. Work stability, safety and simple operation
III. Products sample
PACKING
wooden
Warranty and After-sale service
The warranty of all our testing machine is one year
During this Warranty,it is free to replace the spare parts
Out of this warranty, it only charges the cost of the spare parts
All our testing machines enjoy a long after-sales service
After all machines are delivered to customer’s factory; Seller should assist buyer to finish preparation work, such as electricity supply, water supply, labors and etc.
Marketing
During Last ten years ,we participated Chinaplas fair , Canton Fair,K show and other professional plastic machinery exhibition at home and aboard. Our products are sold around the world,for example , Sweden, Romania,Russia,Canada,Peru,Mexico,Mideast,Southeast Asia,Africa and etc.
Certification
Our advantage
Our Company has good after sales service as well as installation and debugging of machine ,technical training, meanwhile we can provide the special equipments according to customer requirement.
Our products are sold in whole China and exported to many countries and regions such as USA, Japan, Canada, Indonesia, Taiwan, Malaysia, Iran, Singapore, Australia, South Africa, Saudi Aribian, Egypt, Turkey, Philipines, etc. Our company slogan is “Credit by Quality, Market by Service”.
We are appreciated with advance equipment, experience and production power. We provide on time after- sales service. We integrate the design, development, production, sales and after-sales services to our clients.
every machine has Configure single and instructions
Thanks for visiting our website , need more details welcome to contact me any time !
contact person: Sherry chen Tel:008618358758582
skype: fuxinlong02
