Home > Manufacturing & Processing Machinery > Plastic Machinery > Plastic Extruder > Extrusion Line for pp 250kg/h

Extrusion Line for pp 250kg/h

US$ 30,000 - 50,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

fjl

Contact Supplier Request Quote Chat Now

Zhejiang Fuxinlong Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo/shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Zhejiang, China

Brand Name fjl

Model Number FJL-PC- B

Voltage 380/50

Power(W) 110

Dimension(L*W*H) 10.5*2.0*2.2m

Weight 6.5t

After-sales Service Provided Engineers available to service machinery overseas

Certification CE, iso9001,2008

Specifications

extrusion line for pp 250kg/h
making disposable water drinking cups, ice-cream cups, yoghurt cups, lids, dishes, plates and et

Product Description

parts of the machine

I Usage

FJL-PC-B series vertical mono-layer plastic sheet extruder is designed to produce monolayer PP/PS/PE plastic sheet, which is used for making disposable water drinking cups, ice-cream cups, yoghurt cups, lids, dishes, plates and etc.

II Major construction features

The sheet extrusion unit is a combination of extruder, three roll calendar, haul-off unit, winder (including waste sheet winder) and electric control cabinet.

The main parts, such as screw, barrel, screen exchanger, T-die adopt superior alloy steel (38 CrMoAIA) with high hardness, strong corrosions resistance and long operating life after nitrogen treatment.

The screw adopts big L/D (length/diameter) Ratio, equal plasticization and high plasticizing capability.

Non-stop fast screen changer with double-sieve, controlled by hydraulic device, the operation is convenient and improve the production efficiency.

The calendar, haul off unit and winder adopt integration design, fine appearance, convenient and fast installation and adjustment.

The machine frame adopt square steel, to make sure the machine works stably in high speed. The motor is connected with gear box directly, improve production efficiency and lower energy consumption.

III Optional

Motor type screen changer or hydraulic type screen changer.

Independent motor control each roller.

Double-position winder

Main Technical Parameters

Model	FJL-PC-90-B	FJL-PC-100-B	FJL-PC-105-B	FJL-PC-110-B	FJL-PC-115-B	FJL-PC-120-B
Raw Material	PP.PS.HIPS.PE
Sheet Thickness	0.3-2mm
Layer	1
Extrusion Capacity	100kg/h	150kg/h	175kg/h	200kg/h	225kg/h	250kg/h
Screw Dia	Φ90mm	Φ100mm	Φ105mm	Φ110mm	Φ115mm	Φ120mm
L/D Ratio	32:1
Roller Dia	Φ300mm	Φ320mm	Φ350mm	Φ350mm	Φ400mm	Φ450mm
Main Motor Power	37KW	45KW	45KW	55KW	75KW	90KW
Overall Power	90KW	100KW	110KW	120KW	135KW	160KW
Weight(T)	5.5	6	6.5	7	7.5	8
Power Supply	380V/50HZ Three phase four wires

the samples

Packaging & Shipping

WOODEN CASE

Our Services

Warranty and After-sale service

The warranty of all our testing machine is one year

During this Warranty,it is free to replace the spare parts

Out of this warranty, it only charges the cost of the spare parts

All our testing machines enjoy a long after-sales service

powder + additive → mixing → spring feeder/vacuum feeder → extruder → mould and calibrator → forming machine → haul off machine → printing → cutting machine → discharging stacker bracket/belling machine

Our products are sold in whole China and exported to many countries and regions such as USA, Japan, Canada, Indonesia, Taiwan, Malaysia, Iran, Singapore, Australia, South Africa, Saudi Aribian, Egypt, Turkey, Philipines, etc. Our company slogan is “Credit by Quality, Market by Service”.

We are appreciated with advance equipment, experience and production power. We provide on time after- sales service. We integrate the design, development, production, sales and after-sales services to our clients.
