HJCM vertical mill manufactured in our company is a kind of roller mill which can match 2,3 or 4 rollers according to the request. Each roller is composed of fixed rocker arm, frame of rocker arm and hydraulic system which come into grinding power unit , is a complete or standard parts. It is arranged into two compartments, three compartments or four compartments around mill disc.
Look from the technology and economy, HJCM vertical mill is an advanced grinding equipment. Comparing with traditional grinding equipment, the advantages are as the follows:
1---Grind all kinds of different material
2--- Small area
3--- Low consumption
4---Convenient adjustment
5---Quick control response
6---Convenient maintenance(Not need to dismantle the easily wear-out parts
7---Small vibration from start to stop
8---Small noise
9---Strong adaptability
Mill model |
Dia. Of mill (mm) |
Average diameter of mill roller(mm) |
Number of mill roller |
Speed of mill disc (rpm) |
Capacity (t/h) |
Loading power (KW) |
HJCM standard coal vertical mill(Anthracite vertical mill will be discussed in another) | ||||||
HJCM35.30 |
3,500 |
1900 |
3 |
30.9 |
70 |
1400 |
HJCM30.30 |
3,000 |
1900 |
3 |
33.4 |
65 |
1250 |
HJCM28.30 |
2,800 |
1750 |
3 |
34.6 |
55 |
1000 |
HJCM26.30 |
2,600 |
1600 |
3 |
35.9 |
45 |
810 |
HJCM23.30 |
2,300 |
1450 |
3 |
38.2 |
35 |
640 |
HJCM22.30 |
2,200 |
1400 |
3 |
39 |
30 |
590 |
HJCM20.30 |
2,000 |
1250 |
3 |
40.9 |
20 |
430 |
HJCM16.30 |
1,600 |
1000 |
3 |
45.8 |
12 |
250 |
