Specifications
our rotary kiln isequiped with the most advanced hydraulic catch wheelhigh accuracy speed control valve
reduce heat consump
We Jiangsu Haijian Stock Co.,Ltd is a powerful enterprise in manufacturing cement machine, with more than 40 years we have been trading with many countries worldwide and receiced many medals both at hoe and abroad.
The rotary kiln produced by our company can be used for chemical industry,metallurgy industry and etc.The calcination system adopts and high . Compared with the same specification equipment its operation rate and yield increased significantly. To pass through the technology innovation of its calcination system we adopt the most advanced hydraulic catch wheel and high accuracy speed control valve both at home and abroad. In order to raise up automation degree ,industrial TV has been used at the kiln head for monitoring kiln,imitation screen has been used for display of process flow;infrared scanning system has been adopted for sintering zone to directly reflect the burning conditions on the computer. With the use of these new technologies,it is directly in vision,convienent in operation and reliable in use.
Here we give the detailed technical parameter the rotary kiln with 4m dimeter and 60m length as following:
Technique parameter
Specification(m) |
Dia.4m*60 |
||
Capacity (t/d) |
2500 |
||
Slope of the kiln shell(%) |
4 |
||
No. of supporters |
3 |
||
Type of thrust roller |
Hydraulic |
||
|
Rotating speed of kiln |
Main driving(r/min) |
0.41-4.07 |
|
(r/h) |
8.2 |
||
|
Main
Drive |
Motor |
ZSN4-355-092 |
|
(KW) |
315 |
||
Speed regulation range(r/mim) |
~1000 |
||
440 |
|||
Reducer |
Type |
YNA1110-22.4VBR |
|
Total ratio |
22.4 |
||
|
Tachometer generator |
Rated power(KW) |
22 |
|
0~2000 |
|||
Max voltage(V) |
110 |
||
|
Motor |
Type |
Y180L-4 |
|
Rated power(KW) |
22 |
||
Speed scope(r/min) |
1470 |
||
Rated voltage(V) |
380 |
||
Reducer |
Type |
YNS440-45 II R |
|
Total ratio |
45 |
||
Total weight(t) |
434 |
||
