Cement Rotary Kiln With Good After-sale Service

Cement Rotary Kiln With Good After-sale Service photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Haijian
Model Number:
3.5m diameter,54m length
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name Haijian
Model Number 3.5m diameter,54m length

Specifications

our rotary kiln equiped with the most advanced hydraulic catch wheel,high accuracy speed control valve;reduce heat consumption

  The rotary kiln produced by our company can be used  for chemical industry,metallurgy industry and etc.The calcination system adopts and high . Compared with the same  specification equipment its operation rate and yield increased significantly. To pass through the technology innovation of its calcination system we adopt the most advanced hydraulic catch wheel and high accuracy speed control valve both at home and abroad. In order to raise up automation degree ,industrial TV has been used at the kiln head for monitoring kiln,imitation screen has been used for display of process flow;infrared scanning system has been adopted for sintering zone to directly reflect the burning conditions on the computer. With the use of these new technologies,it is directly in vision,convienent in operation and reliable in use. Here we give the detailed technical parameter the rotary kiln with 3.5m dimeter and 54m length as following:

Technique parameter

Specification(m)

Dia.3.5*54

Capacity (t/d)

1500~1800

Slope of the kiln shell(%)

4

No. of supporters

3

Type of thrust roller

Hydraulic

Rotating speed

of  kiln

Main driving(r/min)

0.39~3.9

(r/h)

7.66







Main



Drive

Motor

ZSN4-315-092

(KW)

220

Speed regulation range(r/mim)

~1000

440

Reducer

Type

NZS995-28VIBL

Total ratio

28

Tachometer

generator

Rated power(KW)

22

0~2000

Max voltage(V)

110

Motor

Type

Y200L1-6

Rated power(KW)

18.5

Speed scope(r/min)

970

Rated voltage(V)

380

Reducer

Type

ZSY355

Total ratio

45

Total weight(t)

341
