German technical Paving block and Concrete Block Making Machine
- 20 Set / Sets per Month
- Shanghai/Qingdao
- T/T
- High quality Concrete Block Forming Machine and Paving brick production line
- China professional Paving block and Concrete Block Making Machine
- China professional Brick and Concrete Block Making Machine
- High quality Brick and Concrete Block Making Machine Quality Choice
- foam concrete block making machine
- manual concrete hollow block making machine
Product Details
Condition: | New | Type: | Other, Concrete forming machine | Brick Raw Material: | Concrete |
Processing: | Other, Cement Block forming machine | Method: | Autoclaved Aerated Concrete | Automatic: | Yes |
Capacity: | 9pc/time | Place of Origin: | Shaanxi, China | Brand Name: | BRICTEC |
Model Number: | QFT9 | Voltage: | 380V | Power: | 75kw |
Dimension(L*W*H): | 2870x1800x2950 | Certification: | ISO9001/CE | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
QFT9 Type Concrete Block Making machine
1)Accurate Material distribution and easy for adjustment.
2)Adopt color screen HMI and PLC automatic control line.
3)Adopt the secondary horizontal materail distribution for realizing the block color.
4)Revolution distribution to realize the light bone material distribution.
5)HMI system has the malfunction automation fault monitoring and remote control and monitoring
6)Vibration system shall be adopt the frequency adjustment to ensure that the various product with high quality.
7)It has a heavy frame to extend the service life and make sure stable and reliable operation.
8)Raw material kind: Sandstone,fine coal ash, aggregate chips,ceramic tile,slag,EPS pellet,building rubbish etc
Main Parameter of QFT9 Series Concrete Block Making Machine
QFT9 Series Concrete Block Making Machine | |
Vibration Mode | Table-Vibration |
Height of product(mm) | 60-220 |
Standard Block Dimension | 390x190x190 |
Cycle Time | 15-25 |
Forming Blocks(pc) | 9pc/time |
Pallet Size | 1350X750X45 |
Vibration Frequency | 50-65HZ |
Vibration Force | 100-1500N |
Rating Pressure | 5-12Mpa |
Brief intruduction of Brictec Engineering Co.Ltd
Xi'an Brictec Engineering Co. Ltd not only majors in sale of brick making machines,but also concentrates on the overseas domestic fired brick designing, kiln designing, factory building designing and turn-key project.We provide solutions to brick and tile making industry by a group of professionals who have more than 25 years experiences in this industry.
The Service We Provide
Before sale: Give some advices to customer on how to build a new-brand brick plant and choose the best and economic plant according to the local situation for recovering the investment within a short time; We are also responsible for the offer, flow chart, and detailed information of each machine.
In sale: We will send the technicians to coach brick making machines installation and debug machines. We also train the local operators till they can fully control them.
After sale: Regularly visit customers, solve all the problems with the machine and take advice from customers.
