Cotton canvas is woven by cotton fibers both in warp and in weft,its elongation is relatively low,it is good in mechanical fastening and adhesion with rubber.Cotton conveyor belt has relatively small deformation under high temperature conditions, suitable for short-distance and light-load transportation of materials.Polyester cotton conveyor belt is the upgraded product of cotton conveyor belt,and its tension resistant body is woven by polyester cotton fibers in warp and cotton fibers in weft.Its comprehensive physical and mechanical characteristics are obviously better than that of cotton conveyor blet,especially the belt body is thinner and lighter,the belt has better shock resistance and thus the belt has better use function and can reduce energy and material consumption for users.it is suitable for medium, short-distance and medium-load transportation of materials.
packaging:packed in rolls and covered by fabric water-proof cloth,or clients' requirement also be respected
shipping:within 10-20 days,or depends on the quantity
HYRUBBERS CO.,LTD is specializing In manufacturing, exporting and developing conveyor belt, in the same time rubber sheet, rubber tiles and so on.
The factory founded has 260 people including 220 workers, and 15 engineers and technicians, 25international sales workers, covering an area of 50000 m2, owing 220 sets of main production equipment.
The ISO9001: 2000 certified factory has established a stable and reliable quality control system with a modem management.
Now with the export quantity larger and larger, we become one of the biggest manufacture in North of China.
Specification and technical data of multi-ply cotton,polyester cotton conveyor belt:
Fabric |
Fabric |
Fabric |
Ply thickness |
(N/mm) |
(mm) |
Winth |
Length |
||||||
Warp |
Weft |
2ply |
3 ply |
4ply |
5ply |
6ply |
Upper |
Lower |
|||||
Cotton |
Cotton |
Cotton |
CC-56 |
1.10 |
112 |
168 |
224 |
280 |
226 |
2-8 |
0-4.5 |
400-2500 |
<=300 |
Polyester |
Polyester Cotton |
Cotton |
TC-70 |
1.0 |
140 |
210 |
280 |
350 |
420 |
1.5-8 |
0-4.5 |
400-2500 |
<=300 |
Cover properties of the belts:
Cover grade |
Tensile strength |
Elongation |
Abraion |
Change rate of tensile strength and elongation after aging |
|
Mpa |
|
% |
mm3 |
% |
|
Light (L) |
15 10 |
|
350 300 |
200 250 |
-30~+30 |
Adhesion and elongation of the belt:
Belt |
Adhesive strength |
Elongation |
|||
Between piles |
N/mm |
Longitudinal Elongation at break |
Longitudinal elongation %<= |
||
Rubber thickness<=1.5mm |
Rubber thickness>1.5mm |
||||
Cotton and T/C canvas |
>=2.70 |
>=2.4 |
>=2.7 |
10 |
4 |
Accordance with different applications, we can produce different grades of belt as following:
1) Heat Resistant Belt
According to the temperature of working environments, we can manufacture 3 different grades heating resistant belt, including up to 120℃ grade (HR120), up to 150℃ grade (HR150), up to 180℃ grade (HR180) and up to 200℃ grade (HR200) .Generally used by cements and steel works.
2) Abrasion Resistant (≤90mm3) / super abrasion resistant (≤60mm3) Belt
Generally used for transport the hard or shaped materials, like iron ore, diamond, copper and other minerals.
3) Oil Resistant Belt
Generally used for wood, papermaking, oil-based grain transportation.
4) Acid/Alkali Resistant Belt
Always used in Chemical materials transportation.
5) Cold Resistant Belt
The belt can work in some cold environment, like Northeast of China, Russia and North European countries.
6) Fire Resistant Belt
Always used in underground coal mining, steel works and so on.
7) conventional Belt
Generally used for small powder, grain and block materials.
