TR101 Surface roughness gauge plastic surface roughness
Product Description:
Applications:
TR101 surface roughness gauge is apply to testing various product surface roughness, such as the surface of mobile phone shell, metal product surface, plasticproduct surface, etc.
Specifications:
Item |
TR101 |
Testing parameters |
Ra, Rz, Rq, Rt |
Measuring range (um) |
Ra, Rq: 0.05-15.0 Rz, Rt : 0.1-50.0 |
Sample length (mm) |
0.25, 0.80, 2.50 |
Evaluation length(mm) |
1.25, 4.0, 5.0 |
Stroke length (mm) |
6 |
Indication accuracy |
0.01 |
Indication error |
±(7-10)% |
Variability |
<12% |
Power |
Rechargeable li-battery |
Stylus static force: |
≤ 0.016N |
|
Force measuring rate of change |
≤ 800N/m |
Working temperature |
-20℃~40℃ |
Relative humidity |
<90% |
Weight of Host |
200g |
Size |
106mmx70mmx24mm |
*Shell used to pull aluminum mold design, durable, anti-electromagnetic interference ability significantly, in line with the design of the new trend.
*Using high-speed DSP processor for data processing and calculation, measurement and computation speed is greatly improved.
*Liquid crystal display wide temperature using OLED color display, popular high brightness, no visual angle, is suitable for various occasions.
*The lithium ion rechargeable battery, can work for a long time, no memory effect, can while charging, charging time is short, long battery life.
* Using a dedicated charger or computer USB port for charging, convenient and quick.
*Real-time monitoring of lithium battery power and display, and to remind users to charge with charging progress indication.
*Automatic shutdown function and low power design of software and hardware of the instrument with long working hours, suitable for field use.
*The surface roughness of metal and non-metallic.
*Pocket-size & economically price
*Large measuring range suitable for most materials
*Optimized electric circuit design with transducer structure-design, high integrate power.
*It could test ex-circle, flat surface, conical surface and also test groove larger than 80*30mm.
Standard configuration:
|
|
Name |
QTY |
1 |
Host |
1 |
2 |
Calibration block and bracket |
1 |
3 |
Charger |
1 |
4 |
Data line |
1 |
5 |
Operating manual |
1 |
6 |
Warranty card |
1 |
7 |
Certificate of approval |
1 |
8 |
Instrument case |
1 |
Packing & Shipping:
Packing:pack in suitcase and standard export carton
We supply one year warranty and a longlife maintenance.
We supply 24h online service.
Customer Service
"customer first" aways is our main goal , The technical support department solves all doubts and requirements from users by telephone, Internet, etc. We emphasize on product and service quality.
"Honesty and high quality , customers and service first" is our eternal aim.
Company and factory pictures:
In order to recommend you the most suitable Ultrasonic Flaw Detector and quote you the accurate price, please provide the
information as follows:
1. What forged parts or metal product do you want to detect?
2. How about the product size?
3. What metal is your product made of?
4. Do you have any special requirement for the technical parameters?
5. Which price terms and payment terms could you accept?
6. Please advise which shipping ways you will accept.
7. If you have agent from China, please provide your agent's contact information.
2. How do you ensure the quality of products?
We have a complete quality control system, all of our products were fully 100% inspected by professional QC departments before shipping.
All our products apply to ISO, ASTM, BS, EN, etc. Our products got CE certificate.
