Piston Air Compressor

Piston Air Compressor thumbnail-1
Piston Air Compressor thumbnail-2
Piston Air Compressor thumbnail-3
Piston Air Compressor photo-1
Piston Air Compressor photo-2
Piston Air Compressor photo-3
US$ 5,000 - 48,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Piston
Configuration:
Stationary
Contact Supplier Request Quote Chat Now
Henan YuanJu Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Piston
Configuration Stationary
Power Source AC Power
Lubrication Style Lubricated
Mute Yes
Place of Origin China
Brand Name YUANJU
Model Number L5.5-40/8
Voltage 380V(It can be made by customer's requirement)
Dimension(L*W*H) 2580*1600*1880mm
Weight 3700kgs
Warranty one year
After-sales Service Provided Engineers available to service machinery overseas

The piston air compressor can be designed into oil free type and oil lubricated type. According to clients' technical requirement, the air compressor can be made into L, LW, D, H, Z type...,



Norminal Piston Air Compressor(Application:apply to supply gas source for power for pneumatic tools and equipment, Medium:air , Discharge Pressure:0.7~1.0MPa,Capacity:1.5~300m3/min)
Product Model
Capacity
(m3/min)
Discharge Pressure(Mpa)
Size
L*W*H(mm)
Weight
(t)
Power
(kw)
LW-10/8
10
0.8
2340*910*2070
1.80
65
LW-10/10
10
1
2340*910*2070
1.80
75
LW-20/10
20
1
2632×1550×2332
3.00
132
LW-20/8
20
0.80
2732*1550*2432
3.00
132
LW-30/8
30
0.8
2890*1600*2173
4.12
200
LW-30/10
30
1
2890*1600*2175
4.50
220
L5.5-40/8
40
0.8
2580*1600*1880
3.7
240/250
LW-40/10
40
1
2890*1600*2173
4.12
260
L8-50/8
50
0.8
2630*1652*2235
6.5
315
LW-50/8
50
0.8
2630*1652*2235
6.5
315
L8-50/10
50
1
2360*1685*2235
6.00
315
LW-50/10
50
1
2360*1685*2235
6.00
315
L8-60/8
60
0.8
2380*1500*2560
6.00
350
LW-60/8
60
0.8
2380*1500*2560
6.00
350
LW-65/7
65
0.7
2612*4060*2860
6.00
350
*We could design and make series of oil-free or oil-lubricated air compressor with 11KW to 2000KW power according to requirements of consumers.





Refered piston air compressor photos:

 Piston Air CompressorPiston Air Compressor

Piston Air Compressor
