Hot Sale!China Jinan Bodor Vac-sorb Laser Engraving Cutting Machines BCL-X(H)V
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
CO2
CNC or Not:
Yes
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Portable Fiber Laser Metal Marking Machine PriceUS$ 2,999 - 6,999MOQ: 1 Set -
Co2 Laser Cutting Engraving Machine SaleUS$ 3,000 - 7,999MOQ: 1 Set
-
Small Metal Cutting Machine BCL-FT/YT Form Jinan Bodor Made in ChinaNegotiableMOQ: 1 Set
-
10w Fiber Portable Metal Laser Engraving MachineUS$ 2,999 - 6,999MOQ: 1 Set
-
10w Fiber Galvo Laser // Laser Marking Machine for SaleUS$ 2,999 - 6,999MOQ: 1 Set
Condition
New
Laser Type
CO2
CNC or Not
Yes
Cooling Mode
Water Cooling
Applicable Material
Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Wood
Graphic Format Supported
AI, PLT, DXF, BMP, DST, DWG, LAS, DXP
Place of Origin
Shandong, China
Brand Name
Bodor
Model Number
BCL-X(H)V
Certification
CE, SGS, Other, CE, SGS, FDA
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1. high density honeycomb worktable2.additional adsorption device
3.advanced DSP control system
Product Description
Main Features
1. The machine is Bodor’s unique model, absorbing device fitted under high-density honeycomb working table can avoid winkle and tight edge when cutting flexible materials. Fabrics can be smooth absorbed automatically on working table, which largely prevents waste materials in cutting.
2. The only manufacturer adopts square tube framework in China, with more than 40% higher fuselage strength than iron sheet structure. This design prevents the machine from quivering, resonance and distortion during long term work.
3. Advanced DSP control system, with professional motion control chip, has the function of consecutively high-speed curve cutting and the shortest path selection, which largely improves your working efficiency.
2. The only manufacturer adopts square tube framework in China, with more than 40% higher fuselage strength than iron sheet structure. This design prevents the machine from quivering, resonance and distortion during long term work.
3. Advanced DSP control system, with professional motion control chip, has the function of consecutively high-speed curve cutting and the shortest path selection, which largely improves your working efficiency.
Technical Parameter
| Model | BCL1006X(H)V | BCL1309X(H)V | BCL1610XHV | BCL1812XHV | Option | |
| Working Area | 1000*600mm | 1300*900mm | 1600*1000mm | 1800*1200mm | According to Demands | |
| Laser Power | 40w/50w/60w/80w/100w/130w//150w | |||||
| Laser Type | CO2 Sealed Laser Tube,10.6μm | |||||
| Cooling Type | Water Cooling | |||||
| Engraving Speed | 0-60000mm/min | |||||
| Cutting Speed | 0-40000mm/min | |||||
| Laser Output Control | 0-100% Set by Software | |||||
| Min.Engraving Size | Chinese:2.0mm*2.0mm,English Letter:1.0mm*1.0mm | |||||
| Highest Scanning Precision | 4000DPI | |||||
| Locating Accuracy | ≤+0.01mm | |||||
| Controlling Software | DSP Control System | |||||
| Graphic Format Supported | DST PLT BMP DXF DWG AI LAS,etc | |||||
| Compatible Software | CORELDRAW,PHOTOSHOP,AUTOCAD,TAJIMA,etc. | |||||
| Color Separation | Yes | |||||
| Drive System | High-precision 3-phase Stepper Motor | |||||
| Auxiliary Equipments | Exhaust Fan and Air Exhaust Pipe | |||||
| Power Supply | AC110V/220V+10%,50HZ/60HZ | |||||
| Working Environment | Temperature:0-45C,Humidity5-95%(No Condensate Water) | |||||
| Packing Size | According to the Model | |||||
| Net Weight | According to the Model | |||||
| Option | Honeycomb Worktable,Auto-focus Device | |||||
Applications
Mould industry (construction mould, aviation and navigation mould, wooden mould), advertising, decoration, arts and crafts, electronics, electric appliances, etc.
Materials such as acryl, wood planks(light planks,candlenut wood),bamboo ware, double color board, paper, leather, shell, coconut shell, ox horn, resin animal grease,ABS board, lamp shade, etc.
Materials such as acryl, wood planks(light planks,candlenut wood),bamboo ware, double color board, paper, leather, shell, coconut shell, ox horn, resin animal grease,ABS board, lamp shade, etc.
Our Services
Gaurantee and after sale service:
Gurante e the whole machine for 2 YEARS and laser tube for 4 months, offer lifelong repair, laser tube’s average life is 4000-10000 working hours(depends on the laser power) Offer 24 - hour technical support.
