Hot sale! Fiber laser metal cutting machine BCL- FC from Bodor
- 200 Set / Sets per Month
- Qingdao
- T/T Credit Card
Product Details
Condition: | New | Laser Type: | Fiber Laser | Applicable Material: | Metal |
CNC or Not: | Yes | Cooling Mode: | Water Cooling | Graphic Format Supported: | AI, PLT, DXF, BMP, DST, DWG, LAS, DXP |
Place of Origin: | Shandong, China | Brand Name: | Bodor | Model Number: | BCL-FC |
Certification: | CE, SGS, Other, CE, SGS, FDA | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1.Japanese servo motor2.exchangeable double work table
3.Taiwan HIWIN linear guide rail
2.Integrated design of laser and CNC system. Inside communication ria fiber optic. The power and start & stop of laser all can match the servo motion perfectly.
3.The imported high precision gear, rack transmission system, ensure the high speeding, high precision and good dynamic characteristics. The drives with two synchronized servo motors construction balanced the stress and long service life.
4.Imported pneumatic components, ensure the function of machine without any mistakes. All kinds of gases automatically transition to meet different applications in cutting various of materials and thick plates. convenient and precise, ensure cutting stainless steel with steady, high speed and cleanly
5.The dual-working table reduces the loading and unloading time. It makes easy to move sheets, which adopted the rotating ball support on the working table. The position device and clamps can position the sheet to proof the moving of sheet and ensure the accuracy of processing.
6.Aluminum beam, advanced heat treatment process, high strength, light weight, good rigidity.
7.Imported auto-programming translates CAD drawings to CNC language automatically. Auto-nesting improves material saving and productivity.
8.Imported lens, light path with no need maintain, water cooler and gas positive pressure protection, ensure clean and life of lens.
Widely used in advertising board, metal plate structure, Hv/lv electrical ark production, textile machinery parts, kitchen utensils, car, machinery, elevator, electric parts, spring coil slice, subway line spare parts, etc. industry.
Model | BCL1530FC | BCL1540FC |
MachineSize(Length×Width) | 9600×3200mm | 11600×3200mm |
Max.cuttingrange | 1500×3000mm | 1500×4000mm |
Xaxisstroke | 1500mm | 1500mm |
Yaxisstroke | 3000mm | 4000mm |
Zaxisstroke | 120mm | |
X,Ypositioningaccuracy | 0.05mm | |
X,Yrepositionaccuracy | 0.05mm | |
X,Yrapidmovespeed | 40m/min | |
X,YMax.cuttingrate | 25m/min | |
Lasergenerator | 400W,500W,1000W,2000W | |
Max.loadingcapacity | 1000kg | 1500kg |
Warranty and after sale service:
Warranty the whole machine for 2 YEARS and laser tube for 4 months; offer lifelong repair; laser tube’s average
life is 4000-10000 working hours(depends on the laser power); Offer 24 - hour technical support
About Bodor
Jinan Bodor CNC Machine Co.,Ltd has been always devoting to the research and manufacturing of the CNC products such as Cutting, Engraving and Marking Machines and so on.Today, Bodor CNC has developed to a large worldwide Manufacturing Group, and becomes an excellent leader of the world in this field.
Bodor CNC was founded in 2002, and changed its name to "bodor" formly in 2008.We can supply Laser Cutting, Engraving and Marking Machines,Dot Peen Marking Machines, and many other industrial automation equipments.Meanwhile,we can also supply industrial automation sulutions according to your special needs.
Bodor CNC has earned ourselves a good reputation and ten thousands of faithful customers with our advanced technology,standardized producing management,stable products,and the best services.Through years of international marketing experience,we have established business relationships with customers from North America,West Europe,South Asia,and Middle East,etc.Welcome to join the world of Bodor CNC,you can experience the world-class products and services together with our customers all over the world.
