Home > Products > Fiber Laser Cutting Machine > 200W/ 300W/400W/500W small fiber laser cutting machine for steel
200W/ 300W/400W/500W small fiber laser cutting machine for steel
- 100 Set / Sets per Month
- Qingdao
- T/T Credit Card
Product Details
| Condition: | New | Laser Type: | Fiber Laser | Applicable Material: | Metal |
| Cutting Thickness: | 0.5-20 mm | Cutting Area: | 1300*900mm | Cutting Speed: | 25m/min |
| CNC or Not: | Yes | Cooling Mode: | Water Cooling | Control Software: | cypcut |
| Graphic Format Supported: | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT | Place of Origin: | Shandong, China | Brand Name: | Bodor |
| Model Number: | BCL-FX | Certification: | CE, SGS | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1,High precision2,fast speed ,small heat affected zone
3, high performance-to-price ratio
4,easy to maintain,
Smart Metal Cutting Machine BCL1309FX
High precision, fast speed, small heat affected zone, high performance-to-price ratio, easy to maintain, is the best choice for small format metal cutting!
2. High accuracy for high precision parts and letter cutting.
3. Fast speed: 100 times speed than wire cutting.
4. Small hot affecting area keeps flat and nice cutting line.
5. High performance to price ratio: the price is only 1/3 of that of CO2 laser cutter and 2/5 of that of CNC
| Model | BCL 1309FX | Option | |
| Working Area | 1300*900mm | According to Demands | |
| Laser Module | Fiber Laser Module | ||
| Laser Power | 200-1000W | ||
| Driving Mechanism | Ball Screw | ||
| Max. Cutting Speed | 25m/min | ||
| Positioning Accuracy | ≤±0.08mm/1000mm | ||
| Repeatability Accuracy | ≤±0.04mm | ||
| Laser Wavelength | 1064nm | ||
| Min. Line Width | 0.15mm | ||
| Electrical Source | 380V/50Hz/100A | ||
| Cooling Mode | Water Cooling Chiller | ||
kitchen utensils, car, machinery, elevator, electric parts, spring coil slice, subway line spare parts, etc.
staineless steel, carbon steel, alloy steel, spring steel, copper, aluminum, gold, silver, titanium
metal plate and steel tubes
Our Package Advantage:
1.Our wooden case is after fumigation treatment.Needn’t timber inspection,saving shipping time.
2.All the spare parts of the machine were covered by some soft materials,mainly using pearl wool.
Avoiding all damages that could happen in the delivery process.Then we’ll covered plastic wrap out it tightly,make sure intact of the covered soft materials,also avoiding Waterproof and rust proof.
3.The outmost is wooden case with fixed formwork.
4.The bottom of the wooden case has firm iron jack,convenient to Handling and transport.
Accepting customized requirement
Engineer available to service machinary overseas.
About Bodor
Jinan Bodor CNC Machine Co.,Ltd was founded in 2002.In 2008 we formally changed name to Bodor with RMB 10 million registered capital.For 12 years,Bodor laser has always been devoted in studying and manufacturing laser cutting,engraving and marking etc.
With all Bodor staff persistence and hard working,Bodor laser has developed to a large-scale international manufacturing company.More accuracy,more automatically and higher quality products with intimate after-sales service enables Bodor be the leader of laser industry.Suitable services for customers,2-year warranty products,standard scientific management make bodor earn the best reputation and word-wide trusted customers.
For 12 years,Bodor laser machines cover all Chinese market and also very popular in America,West Europe,South Asian,East Asian etc. More than 80 countries. Bodor lasers will try our best to serve for you suitable laser solutions. Welcome you to join Bodor family,share top laser products and services together with word-wide customers.
Bodor certificate
Bodor laser cutting machine --Exhibition show
Our Factory
Our product line
--Metal cutting machine
--Laser engraving cutting machine
--Fiber laser machine
--Laser marking machine
--Small fiber laser making machine
Laser machine--Our Customer in Factory
Our Team
Contact Us
- Jinan Bodor CNC Machine Co., Ltd.
- Contact nameSandy Geng
- Phone86-0531-88690051
- AddressHuaya Industrial Park, Kanghong Road, High-Tech Zone
