Hot Sale! Jinan Bodor Large Format Laser Cutting Machine for Auto Supplies BCL-BH
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
CO2
Applicable Material:
Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Wood
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai Guangzhou Ningbo Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mix Laser Cutting MachineNegotiableMOQ: 1 Set -
Chia Jinan Bodor Co2 Laser Cutting Bed BCL-BC With Dust -proof and Smoke-proof FunctionNegotiableMOQ: 1 Set
-
Hot Sale! Jinan Bodor Co2 Laser Cutting Bed BCL-BC With Dust -proof and Smoke-proof FunctionNegotiableMOQ: 1 Set
-
China Jinan Bodor Drawing Pen Laser Cutting Machine Made in ChinaNegotiableMOQ: 1 Set
-
Large Format Cnc Laser Cutting Wood Machine PriceNegotiableMOQ: 1 Set
Condition
New
Laser Type
CO2
Applicable Material
Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Wood
Cutting Speed
0-30000mm/min
CNC or Not
Yes
Cooling Mode
Air Cooling
Control Software
DSP Control System
Graphic Format Supported
AI, PLT, DXF, BMP, DST, DWG, LAS, DXP
Place of Origin
Shandong, China
Brand Name
Bodor
Model Number
BCL-BH
Certification
CE, SGS, Other, CE, SGS, FDA
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
advanced DSP control systemhigh quality laser tube
red light positioning device
optional automatic transmission system
Product Description
Main Features
1.In order to achieve large format cutting requirement, Bodor specially pushes-off laser cutting machine, which is applicable to auto decoration’s cutting and multi-plastic’s cutting, widely used in auto accessories and other industries.
2.Adopting machine tool working chassis which is more stable and stronger, so that stability and precision can be assured in high-movement processing.
3.Transmitting Motor system adopts linear guide guiding and precision gear, along with advance high-accurate motor and driver controlled by DSP system, which assures the processing precision and speed.
4.Stable and long lifespan high quality laser tube assures the work piece’s incision smooth, no need secondary operation.
5.Specially processing full-open net worktable, ensures easy and fast material-taking.
6.Special cutting equipment can save time, low down cast, and improve work efficiency to you.
7.Arranged with red dot position equipment, which could indicate position of laser head, getting rid of manual-position’s annoyance.
2.Adopting machine tool working chassis which is more stable and stronger, so that stability and precision can be assured in high-movement processing.
3.Transmitting Motor system adopts linear guide guiding and precision gear, along with advance high-accurate motor and driver controlled by DSP system, which assures the processing precision and speed.
4.Stable and long lifespan high quality laser tube assures the work piece’s incision smooth, no need secondary operation.
5.Specially processing full-open net worktable, ensures easy and fast material-taking.
6.Special cutting equipment can save time, low down cast, and improve work efficiency to you.
7.Arranged with red dot position equipment, which could indicate position of laser head, getting rid of manual-position’s annoyance.
Technical Parameter
| Model | BCL1730B | BCL1835B | Optional |
| Applicable Materials Area | 1700*3000mm | 1800*3500mm | According to Demands |
| Actual Cutting Area | 1650*3000mm | 1750*3500mm | |
| Laser Power | 60w/80w/100w/130w//150w | ||
| Laser Type | CO2 Sealed Laser Tube , 10.6μm | ||
| Cooling Type | Water Cooling | ||
| Cutting Speed | 0-30000mm/min | ||
| Laser Output Control | 0-100% Set by Software | ||
| Min. Engraving Size | Chinese: 2.0mm*2.0mm, English Letter:1.0mm*1.0mm | ||
| Highest Scanning Precision | 4000DPI | ||
| Locating Accuracy | ≤+0.02mm | ||
| Controlling Software: | DSP Control System | ||
| Graphic Format Supported | DST PLT BMP DXF DWG AI LAS,etc | ||
| Compatible Software | CORELDRAW,PHOTOSHOP, AUTOCAD,TAJIMA,etc. | ||
| Color Separation | Yes | ||
| Drive System | High-precision 3-phase Stepper Motor | ||
| Auxiliary Equipments | Exhaust Fan and Air Exhaust Pipe | ||
| Power supply | AC110V/220V+10%,50HZ/60HZ | ||
| Working Environment | Temperature:0-45C,Humidity 5-95%(No Condensate Water) | ||
| Option | Blade Worktable | ||
Applications
Applicable industry:
Mould industry (construction mould, aviation and navigation mould, wooden mould), advertising, decoration, arts and crafts, electronics, electric appliances, etc.
Applicable Materials:
Auto supplies manufacturing industry,materials such as acryl, wood planks(light planks,candlenut wood),bamboo ware, double color board, paper, leather, shell, coconut shell, ox horn, resin animal grease,ABS board, lamp shade, etc.
Mould industry (construction mould, aviation and navigation mould, wooden mould), advertising, decoration, arts and crafts, electronics, electric appliances, etc.
Applicable Materials:
Auto supplies manufacturing industry,materials such as acryl, wood planks(light planks,candlenut wood),bamboo ware, double color board, paper, leather, shell, coconut shell, ox horn, resin animal grease,ABS board, lamp shade, etc.
Our Services
Warranty and after sale service:
Warranty the whole machine for 2 YEARS and laser tube for 4 months; offer lifelong repair; laser tube’s
average life is 4000-10000 working hours(depends on the laser power); Offer 24 - hour technical support.
