double or more head co2 laser cutting bed
- 100 Set / Sets per Month
- Qingdao Tinajin
- T/T Credit Card
Product Details
Condition: | New | Laser Type: | CO2 | Applicable Material: | Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood |
Cutting Area: | 1300*2500mm | Cutting Speed: | 0-30000mm/min | CNC or Not: | Yes |
Cooling Mode: | Water Cooling | Control Software: | RD Control System | Graphic Format Supported: | AI, PLT, DXF, BMP, DST, DWG, LAS, DXP |
Place of Origin: | Shandong, China | Brand Name: | Bodor | Model Number: | BCL-B |
Certification: | CE, SGS, Other, CE, SGS, FDA,TUV | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1.Computer control easy for complex design2. High accuracy and fast speed
3. CE,TUV,SGS,FDA certificated
Fully open blade working platform, machine tool and stable working chassis, high accuracy stepper motor driver, optional automatic transmission system, make your work more stable and accurate.
2. Steady chassis: Stability and precision during high speed work.
3. Moving system adopts Taiwan HIWIN linear guide and precision gear, matched up with advanced DSP-controlled 3-phase stepper motor to ensure the working accuracy.
4. High efficiency tube with stable laser path, life time around 10000 hours.
Model | BCL1325B | BCL1625B | BCL 1830B | BCL 2030B | BCL 2060B | |
Working Area | 1300*2500mm | 1600*2500mm | 1800*3000mm | 2000*3000mm | 2000*6000mm | |
Laser Power | 60w/80w/100w/130w/150w | |||||
Laser Type | Sealed Co2 Laser Tube,10.6μm | |||||
Cooling Type | Water Cooling | |||||
Cutting Speed | 0—30000mm/min | |||||
Laser Output Control | 0—100% Software Setting | |||||
Smallest Character Engraving | 2.0*2.0mm1.0*1.0mm / English 1.0mm*1.0mm | |||||
Highest Scanning Precision | 4000DPI | |||||
Locating Precision | ≤+0.01mm | |||||
Controlling Software | RD Control System | |||||
Graphic Format Supported | DST PLT BMP DXF DWG AI LAS,etc | |||||
Compatible Software | TAJIMA,CORELDRAW,PHOTOSHOP,AUTOCAD,All Type of AUTOCAD Sofeware in Cloth | |||||
Color Separation | Yes | |||||
Drive System | High-precision 3-phase Stepper Motor | |||||
Auxiliary Equipments | Exhaust Fan and Air Exhaust Pipe | |||||
Power Supply | AC110V/220V+10%,50HZ/60HZ | |||||
Option | Up&Down Table(Length:500mm),Honeycomb Worktable,Rotary Device Red Dot Position System,Auto-focus Device |
Applicable industry:
Mould industry (construction mould, aviation and navigation mould, wooden mould), advertising, decoration, arts and crafts, electronics, electric appliances, etc.
Applicable Materials:
materials such as acryl, wood planks(light planks,candlenut wood),bamboo ware, double color board, paper, leather, shell, coconut shell, ox horn, resin animal grease, ABS board, lamp shade, etc.
Samples:
Packaging
About Us
Contact Us
- Jinan Bodor CNC Machine Co., Ltd.
- Contact nameSandy Geng
- Phone86-0531-88690051
- AddressHuaya Industrial Park, Kanghong Road, High-Tech Zone
