Specifications
Diameter of Hole: 230-300 mmDrilling Depth: 30 -200 m
3.Air Consumption: 16-30 m3/min
4.16-30 m3/min: 10.5-24.6 Mpa
Introductions:
KW10 Water Well Drill Rig is a light, efficient and multifunction drilling plants. The power system is provided by the air compressor. It is
well received by professionals of drilling well, irrigation well, geothermy well and other well holes, especially for water intake projects in
mountain areas and lithostrome. The drill rig can drill holes in various stratum and the diameter of the hole reaches 254mm. It uses the
latemodel hydraulics, large torque hydraulic motor and cylinder system powered by wellknown multicylinder engine. Its unique pump
package design easy to maintenance and lower cost of upkeep. Its centralized hydraulic control board facilitates operation. The drill
rig adopts crawler chassis and cross-country performance is very well.
Specification of KW10 Multi-Function Well Drill Rig
Structure |
Parameters |
Diameter of Hole |
Φ230-300 mm |
Drilling Depth |
150 -200 m |
Air Consumption |
16-30 m3/min |
Working Pressure |
1.05-2.46 Mpa |
Ground Clearance |
280 mm |
Support Cylinder Stroke |
1000 mm |
Feed Cylinder Stroke |
2400 mm |
Feed Power |
45000 N |
Lift Power |
95000 N |
Speed of Rotator |
Low: 60 rpm; Quick: 105 rpm |
Climb Capacity |
25 |
Traveling Speed |
0-2.5 km/h |
Weight |
7500 kg |
Dimension |
5100×2300×2850(L*W*H) |
Specification of LGCY-26/20 Screw Air Compressor
Structure |
Parameters |
Complete Machine | |
Model |
LGCY-26/20 |
Capacity |
26(m³/min) |
Working Pressure |
2.5(Mpa) |
Weight |
4500(kg) |
Dimension L×W×T |
4600×1950×2850(mm) |
Tyre Size × Number |
7.50-16×4 |
Diesel Engine | |
Diesel Manufacturer |
Cummins |
Type |
6LTAA8.9-C360 |
Model |
Vertical, line,Water-cooled |
Breathing Method |
Inter-cooling |
Bore × Stroke × Cylinder |
114×145×6 |
Rated Power |
265 (kw) |
Diesel Oil Capacity |
27.6(L) |
Tank Capacity |
400(L) |
Voltage |
24(L) |
Air Compressor | |
Model |
SKY11G194 |
Compress Grade |
2 |
Compressor Oil Capacity |
48 |
|
Air Supply Valve Specification × No. |
G2×1, G3/4×1 |
Company Profile
Kaishan General Machinery Co,.Ltd (Beijing) is specialized in producing air compressor and drill rig, it's located in capital of China and more convenient communication
with foreign customers.Our factory covers an area of 514,800 m2 with a total assets of 6 billion RMB.There are 6000 staff members including 1075 technicians.
We established an effective complete quality control system and obtained the certificate of ISO9001:2000 Quality System Authentication, imported advanced production
equipment:The Germany KAPP-RX screw rotor grinding machine,The Germany HEXAGON high-precision 3-coordinate measuring machines wenzel, JapanMHU630A machine center, the U.K. HOLROYD NC screw rotor milling machine, Japan heated treatment production line etc.
International precision processing equipment and firstclass testing equipment guarantee the excellent and stable of products.
In the past, our company remains a leader in air compressor and mine drill rig field. We are a well-established firm in the industry, and we enjoy good relations with chain stores and distributors in China. Our products are competitive in quality and enjoy a very good reputation
in both domestic and international markets.Our products are not only sold to domestic largescale enterprises,but also exported to Southeast Asia, North America and Europe
India,Iran and other countries and regions. We sincerely hope to establish longterm cooperation relationship with you on the basis of mutual benefit,reciprocity and common
development!
