Help CenterLarge Format Auto-feed Laser Cutting Machine BCL-BA Made in China
Related Products
-
Large Format Auto-feed Laser Cutting Machine BCL-BA From Jinan BodorNegotiableMOQ: 1 Set -
Hot Sale! Bodor Large Format Auto-feed Laser Cutting Machine BCL-BA Made in ChinaNegotiableMOQ: 1 Set
-
China Jinan Bodor Large Format Auto-feed Laser Cutting Machine BCL-BANegotiableMOQ: 1 Set
-
For Leather Cloth Large Format Auto-feed Laser Cutting Machine BCL-BA for SaleNegotiableMOQ: 1 Set
-
Eastern Multi-head China Fabricating Mechines for SaleNegotiableMOQ: 1 Piece
Specifications
automatic transmission systemautomatic collecting device
optional track correction device, multilayer feeding device
2.Crawler correction device can prevent crawler belt dislocation when working.
3.Cloth auto-collecting device is very convenient for users to collect cloth.
4.Multi-layer feeding device is already for users to process multi-layer cloth at the same time.
5.To meet the demand of cutting in large width, Bodor laser cutting machine bed adopts the machine tool-level chassis to ensure the stability and accuracy in high speed working.
6. The moving system adopts Taiwan Hiwin linear guide and precision gear, matched up with the advanced DSP-controlled 3-phase stepper motor to ensure the working accuracy.
6.News-style high-efficiency laser tube is adopted. Laser beam is more stable than the traditional type. Usage age is more than 10000 hours.
| Model | BCL1625BA | BCL1830BA | Option |
| Working Area | 1600*2500mm | 1800*3000mm | According to Demands |
| Laser Power | 60w/80w / 100w / 130w / 150w | ||
| Laser Type | CO2 Sealed Laser Tube,10.6μm | ||
| Cooling Type | Water Cooling | ||
| Cutting Speed | 0—30000mm/min | ||
| Laser Output Control | 0—100% Software Setting | ||
| Smallest Character Engraving | 2.0*2.0mm1.0*1.0mm / English 1.0mm*1.0mm | ||
| Highest Scanning Precision | 4000DPI | ||
| Locating Precision | ≤+0.01mm | ||
| Controlling Software | DSP Control System | ||
| Graphic Format Supported | DST PLT BMP DXF DWG AI LAS,etc | ||
| Compatible Software | TAJIMA,CORELDRAW,PHOTOSHOP,AUTOCAD,All type of AUTOCAD Sofeware in Cloth | ||
| Color Separation | Yes | ||
| Drive System | High-precision 3-phase Stepper Motor | ||
| Auxiliary Equipments | Exhaust Fan and Air Exhaust Pipe | ||
| Power Supply | AC110V/220V+10%,50HZ/60HZ | ||
Garments sampling, large format tailoring ,leather industry ,shoemaking ,decoration,furniture ,advertisement, packing and printing ,molding and artcrfts industries,etc.
Applicable Materials:
Fabrics,cloth, laser, paper, bamboo ware, acryl, glass, thin film and canvas, etc.
Warranty and after sale service:
Warranty the whole machine for 2 YEARS and laser tube for 4 months; offer lifelong repair; laser tube’s
average life is 4000-10000 working hours(depends on the laser power); Offer 24 - hour technical support.
About Bodor
Jinan Bodor CNC Machine Co.,Ltd has been always devoting to the research and manufacturing of the CNC products such as Cutting, Engraving and Marking Machines and so on.Today, Bodor CNC has developed to a large worldwide Manufacturing Group, and becomes an excellent leader of the world in this field.
Bodor CNC was founded in 2002, and changed its name to "bodor" formly in 2008.We can supply Laser Cutting, Engraving and Marking Machines,Dot Peen Marking Machines, and many other industrial automation equipments.Meanwhile,we can also supply industrial automation sulutions according to your special needs.
Bodor CNC has earned ourselves a good reputation and ten thousands of faithful customers with our advanced technology,standardized producing management,stable products,and the best services.Through years of international marketing experience,we have established business relationships with customers from North America,West Europe,South Asia,and Middle East,etc.Welcome to join the world of Bodor CNC,you can experience the world-class products and services together with our customers all over the world.
