Steam or Water Used Single Pot Sterilizing Retort

Steam or Water Used Single Pot Sterilizing Retort thumbnail-1
Steam or Water Used Single Pot Sterilizing Retort thumbnail-2
Steam or Water Used Single Pot Sterilizing Retort thumbnail-3
Steam or Water Used Single Pot Sterilizing Retort thumbnail-4
Steam or Water Used Single Pot Sterilizing Retort photo-1
Steam or Water Used Single Pot Sterilizing Retort photo-2
Steam or Water Used Single Pot Sterilizing Retort photo-3
Steam or Water Used Single Pot Sterilizing Retort photo-4
US$ 15,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
JINTAI
Contact Supplier Request Quote Chat Now
Zhucheng Jintai Food Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name JINTAI
Model Number JT-QS
Usage Canned Food
Type Autoclave
Voltage adjustable

steam or water used single pot  sterilizing retort




Product Description





application scope:



High-temperature sterilization of the Tinplate canned or Bottles canned





Product Features



1. Semi-automatic computer control the temperature, sterilization time, pressure protection, product cooling.





2. Energy saving and easy to operate.

3. It can use hot water cycle sterilization and steam sterilization.

4. It is suitable for vacuum package, cans, glass bottles, and plastic package, edible and other food.

5. Setting several sterilization processes according to different products.

6. Pure stationary steam-sterilization

7. Mechanical overpressure protection

8. Quick Opening Gate safety interlock protection

9.Inflatable silicone ring



Basic performance



1. Mechanical security chain

2. Mechanical overpressure protection

3.Gas Hammer silencers

4. Compulsory sterilization water flow

5.speed of Replacement water: <3 minutes>



Model:

diameter(mm)

length (mm)

volume(m³)

water pump



quantity

model

  body thickness

Sterilizer pot



φ500

800

0.20

2

DN20

4



φ600

1000

0.35

2

DN32

4



φ700

1200

0.57

2

DN40

4



1500

0.69

2

DN40

4



1800

0.80

2

DN40

4



φ900

1800

1.37

2

DN65

4



φ1000

2200

2.03

2

DN65

4



2400

2.18

2

DN80

4



2600

2.34

2

DN80

4



3000

2.66

2

DN80

4



φ1200

2700

3.56

2

DN80

5



3000

3.90

2

DN80

5



3600

4.58

2

DN100

5



4000

5.03

2

DN100

5



φ1300

3000

4.62

2

DN100

5



4000

5.95

2

DN100

5



5000

7.27

2

DN100

5



φ1500

4000

8.04

2

DN125

6



5000

9.80

2

DN125

6



6000

11.58

2

DN125

6





Design pressure

0.35 Mpa

Maximum working pressure

0.30 Mpa

The material of pot body

Sus304

Design temperature

147°C





steam or water used single pot sterilizing retort


Packaging & Shipping

steam or water used single pot sterilizing retort


FAQ




Port: Qingdao
Minimum Order Quantity: 1 Set/Sets
Supply Ability: 5-10 Set/Sets per Month
Payment Terms: T/T
Packaging Details: wooden box packag
Delivery Detail: after receiving deposit 30days




Company Information
 We Jintai has been in the sterilizing retort feild for more than 7 years and gain a good reputation from our customers

all overthe world. Hope we can develop a long-term win-win business relationship.
