Home > Industrial Equipment & Components > Compressor > Compressor Unit > High Efficent Energy Saving Explosive-proof Screw Air Compressor for Mine

High Efficent Energy Saving Explosive-proof Screw Air Compressor for Mine

Name: High Efficent Energy Saving Explosive-proof Screw Air Compressor for Mine
Brand: kaishan
SKU: 101482155
Availability: InStock

High Efficent Energy Saving Explosive-proof Screw Air Compressor for Mine thumbnail-1

High Efficent Energy Saving Explosive-proof Screw Air Compressor for Mine photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Type:

Screw

Configuration:

Stationary

Power Source:

AC Power

Contact Supplier Request Quote Chat Now

Kaishan General Machinery Co., Ltd. (Beijing)

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjain port ningbo port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Screw

Configuration Stationary

Power Source AC Power

Lubrication Style Lubricated

Mute Yes

Place of Origin Zhejiang, China

Brand Name kaishan

Model Number KM-75

Specifications

1.direct manufacture
2. competitive price
3.High efficiency
4.Low oil consumption

1 Adopt famous imported air ends .so it attains such advantages: high precision, smooth operation, low noise, high reliability, long lifespan, low maintenance cost, low oil cost and etc.

2 A set of air-flow controlling system is adopted from Austria with high stability.

3 the load regulation between the range of 0and 100 helps to adjust the power consumption according to the actual amount of air used.

4 Safe in operation, it is explosive-proof and prevents from over-loading, short circuit, loss of phrase and electricity leak. Its warning system functions under the condition of over temperature, clogging of air filter, oil filter and oil separation filter. In addition, it shuts down in condition of over temperature.

5 the pneumatic tools and spraying equipment can be used in digging tunnel under the pit often confront the problem of low efficiency of compressed air provided because the pressure decreases for the long pipeline. This kind of air compressor is also applicable in the tunnel construction engineering.

MLG series coal mine with screw air compressor technology parameters
MODEL	MLGF3.6/7	MLGF6/7	LGF7.6/7	MLG10/8
Capacity(M3/min)	3.6	6	7.6	10
Working Pressure(MPa)	0.7	0.7	0.7	0.8
voltage(V)	380/660	380/660(660/1140)	380/660(660/1140)	380/660(660/1140)
Power(kw)	22	37	45	55
Motors explosion-proof mark	ExdI	ExdI	ExdI	ExdI
Weight(kg)	1160	1600	1700	2250
Dimension(mm0	2300×960×1330	2730×1100×1400	2940×1200×1480	2940×1200×1480
gauge(mm)	600/762/900	600/762/900	600/762/900	600/762/900
MODEL	MLGF13/7	MLGF16/8	LGF21/8	MLG25/8
Capacity(M3/min)	13	16	21	25
Working Pressure(MPa)	0.7	0.8	0.8	0.8
voltage(V)	380/660(660/1140)	380/660(660/1140)	380/660(660/1140)	380/660(660/1140)
Power(kw)	ExdibI	ExdibI	ExdibI	ExdibI
Motors explosion-proof mark	ExdI	ExdI	ExdI	ExdI
Weight(kg)	2600	2648	3725	3760
Dimension(mm0	3240×1210×1550	3240×1210×1550	3560×1360×1695	3740×1360×1745
gauge(mm)	600/762/900	600/762/900	600/762/900	600/762/900
MODEL	MLGF30/8	MLGF35/8	MLGF42/8	MLG 42/8
Capacity(M3/min)	30	35	42	42
Working Pressure(MPa)	0.8	0.8	0.8	0.8
voltage(V)	660/1140	660/1140	660/1140	660/1140
Power(kw)	185	200	250	250
Motors explosion-proof mark	ExdI	ExdI	ExdI	ExdI
Weight(kg)	4235	4255	5860	5860
Dimension(mm0	3850×1430×1850	3850×1430×1850	4450×1600×2000	4300×1600×2000
gauge(mm)	600/762/900	600/762/900	600/762/900	600/762/900
