Intel Atom D525 17 Inch Fanless Industrial Panel pc

Name: Intel Atom D525 17 Inch Fanless Industrial Panel pc
Brand: Geshemtech
SKU: 101475845
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Products Status:

Stock

Type:

Panel PC

Brand Name:

Geshemtech

Shenzhen Geshem Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Type Panel PC

Brand Name Geshemtech

Model Number PPC-GS1701T

Place of Origin Guangdong, China

Product Description

Features:

l Intel ®ATOM D525 1.8GHz Processor

l 17″ TFT LED screen

l Resistive touch screen

l Fully-sealed fanless design, suitable for harsh industrial environment applications

l 2GB memory (DDRIII), up to 4GB memory

l 4*USB /4*COM/1*VGA

l 2*RJ45 Gigabit LAN

l Color: Slivery/Black/White

Specifications:

Display Feature	Display Screen	17″ TFT LED
	Resolution	1024*768
	Brightness	350 cd/m2
	Contrast ratio	400:1
	Touch Screen	Resistive touch screen
Performance	Chipset	Intel ®ATOM D525 + ICH8M
	Memory	2G memory (DDRIII), up to 4GB
	Hardware Monitor	Monitors voltage, TEMP and CPU fan speed
	Watchdog Timer	Programmable 256 levels timer interval, from 1 to 255 sec, setup by software
	Storage	HDD:320GB 2.5'HDD CF :(Optional)
	Power Supply	100~240VAC/50~60Hz (Power adapter) 12VDC/5A or 9~36VDC Optional (No power adapter)
	Power Dissipation	28W (standby); 40W (Running MaxPower 100%)
O/S	Operating System	Windows XP/ Windows 7/ Linux
I/O Interface	USB	4*USB2.0 Ports
	Serial Port	4RS232 (1~2RS485 Optional)
	Ethernet	2* RTL8111DL 10/100/1000Mbps RJ45
	Audio	1*Line out
	Display	1*VGA
Environmental	Anti-vibration	5-19Hz/1.0mm amplitude;19-200Hz/1.0g, acceleration
	Anti-shock	10g acceleration, 11ms duration
	IP Level	Front panel IP65(Optional)
	Reliability	MTBF≥50000h; MTTR≤0.5h
	Operating Temperature	-10℃~50℃ (with air flow)
	Storage Temperature	-20℃ ~60℃
	Operating Humidity	95% @40℃, non-condensing
Mechanical	Dimensions	400mm(L)×320mm(W)×60 mm (H)
	Material	High-strength and elegant Al-alloy panel
	Weight	6.75kg/8.75kg (NET./GROSS.)
	Color	Slivery/Black/White
