New Products Dimmer Actuator 4-Fold(KNX/EIB Intelligent Home and Building Controlling System
US$ 250 - 450
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
eastkame
Model Number:
KSSV-0404D
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
New Products Glass Touch Panel Dimmer Light Switch Touch Light Switch for HotelUS$ 160 - 250MOQ: 1 Set -
New Products Intelligent Remote Control Switch and Touch Switch Touch Light Switch for Hotel/home Room AutomationUS$ 160 - 250MOQ: 1 Set
-
New Products Smart Life Used Z-wave Touch Screen Wall Switch 3 Gang Remote and Touch Light Switch for Hotel/home Room AutomationUS$ 160 - 250MOQ: 1 Set
-
4 Gang Touch Screen Light Control SwitchUS$ 160 - 250MOQ: 1 Set
-
4 Gang Touch Screen Dimmer Light Switch Touch Wall SwitchUS$ 160 - 250MOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
eastkame
Model Number
KSSV-0404D
New Products Dimmer Actuator 4-Fold(KNX/EIB Intelligent Home and Building Controlling System
Detailed Functions:
-Switching the LED light
-Relative dimming
-Absolute dimming
-Status report, error report
-Setting 15 scenes
-Staircase lighting function
-Bus recovery (or reset) function
-Preset value and modify preset value functions
-Switch/relative dimming via manual buttons
Detailed Spec:
| Item | Parameter | Detailed Spec |
| Power supply | Working voltage | 21-30V DC, via EIB bus |
| Input voltage | 230 V AC (50/60Hz) | |
| Output | KA/D 0103.1---1 channel | Max. output capacity 500W per channel |
| Output voltage | 230 V AC (50/60Hz) | short-circuit and excess temperature protection |
| Max. Leakage Loss | 5W | |
| Connections | EIB/KNX | EIB bus connection terminal |
| Input, Load Circuits | Screw terminals | |
| Operation | Button and red LED | For assigning physical address |
| display | Green LED flashing | Indicate the device running normally |
| Type of protection | IP 20 | EN 60 529 |
| Temperature | Operation | -5 °C ... + 45 °C |
| Storage | -25 °C ... + 55 °C | |
| Transport | -25 °C ... + 70 °C | |
| Ambient | Humidity | <93%, except dewing |
| Mounting | On 35mm DIN rail | |
| Dimensions | KA/D 0103.1--- 90×71.5×60 mm | |
| CE norm | CE norm In accordance with the EMC guideline and the low voltage guideline | |
| Certification | EIB/KNX certified | |
