Azbil Smart Pressure Transmitter PTG72T Remote Seal with Ferrule Clamp Type
OVERVIEW
The Smart Pressure Transmitter model PTG is a
high- performance, highly reliable gauge
pressure transmitter. Based on Azbil
Corporation's proven Smart Transmitter
technologies, the model PTG offers improved
performance and reliability with size, weight and
cost advantages. An optional, built-in digital
indicator allows the pressure transmitter to be
used in a wide variety of applications.
The model PTG can also enable two-way
communications between CommPad (Smart
Communicator), or HART 375 communicator,
and, via DE protocol, a TDCS3000 or 3000X
and a database, thus facilitating self-diagnosis,
range resetting, and automatic zero adjustment
perations.
Azbil PTG series Smart Pressure Transmitter
Model PTG71G screw type
FEATURES
Compact and lightweight
· Approx. 0.9 kg (Screw connection type)
Broad range setting
· Range from -100 kPa to 50 MPa.
· Span from 2.0 kPa to 50 MPa.
Note) Screw connection type. Covered with five ranges.
Remote communication
Any range can be set using the Smart
communicator or the HART communicator
(available separately).
This further increases range flexibility and keeps
inventory down.
Built-in digital indicator
The built-in digital indicator option effectively
checks output on site.
Type of protection
· Water and dust proof for IEC IP67
· FM Explosionproof
· FM Dust-ignition-proof
· FM Intrinsically safe
· KOSHA Flameproof
· NEPSI Flameproof
· NEPSI Dust ignition-proof
· ATEX Flameproof
China RoHS
This device is used in the Oil & Gas, Petrochem-
ical, Chemical, Pulp & Paper, Food & Beverage,
Machinery, Steel/Metal & Mining, and Automo-
bile industries and therefore does not fall under
the China RoHS Legislation.
If this device is used in semiconductor manufac-
turing equipment, labeling on the device and
documents for the China RoHS may be required.
If such documents are required, consult an Azbil
Corp. representative.
External views of the PTG series
Model PTG7_G Model PTG7_B Model PTG7_F Model PTG7_S
(Screw type) (Flush diaphragm type) (Flange type) (Ferrule clamp type)
Model PTG7_S Model PTG7_K Model PTG7_K
(Ferrule cap nut type) (Ferrule clamp type (Ferrule cap nut type
with cooling tower) with cooling tower)
Model PTG7_T Model PTG7_T
(Remote seal with ferrule clamp type) (Remote seal with ferrule cap nut type)
