Oil and Gas Industry Temperature Transmitter 6440 Price and Supplier (with RTD Sensor)

US$ 100 - 10,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Singapore

Model Number:

6440

Xian XK Sensor Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

XI AN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Singapore

Model Number 6440

Product Description

6440 temperature transmitters

Original Transmitter

Highly accurate head and rail mount temperature transmitter

2.Technical Parameter

Accuracy	+ 0.15° C (+0.27° F) for Pt100 RTD (optional 0.10° C (+0.18° F))
D/A Accuracy	+0.03% of span
Ambient Temperature Effects	0.003°C per 1.0°C (1.8°F) change in ambient (Pt100 RTD)
Stability	.15% of Reading or .15°C for 2 years (optional 0.25% or 0.25°C 5 yr)
Inputs	2 x 2-, 3-, and 4-wire RTDs, thermocouple, millivolt, ohm
Supply Voltage	12 - 42.2V in HART Protocol (Selectable HART revisions 5 and 7)
Form Factor	DIN A Head Mount
Accuracy	+ 0.15° C (+0.27° F) for Pt100 RTD
D/A Accuracy	+0.03% of span
Ambient Temperature Effects	0.003°C per 1.0°C (1.8°F) change in ambient (Pt100 RTD)
Stability	0.15% of Reading or .15°C for 2 years
Inputs	1 x 2-, 3-, and 4-wire RTDs, thermocouple, millivolt, ohm
Supply Voltage	12 - 42.2V in HART Protocol
Form Factor	Rail mount
Accuracy	+ 0.15° C (+0.27° F) for Pt100 RTD
Ambient Temperature Effects	0.003°C per 1.0°C (1.8°F) change in ambient (Pt100 RTD)
Stability	.15% of Reading or .15°C for 2 years
Inputs	1 x 2-, 3-, and 4-wire RTDs, thermocouple, millivolt, ohm
Supply Voltage	9 - 32V in FOUNDATION Fieldbus Protocol
Form Factor	DIN A Head Mount
Accuracy	+ 0.15° C (+0.27° F) for Pt100 RTD
Ambient Temperature Effects	0.003°C per 1.0°C (1.8°F) change in ambient (Pt100 RTD)
Stability	.15% of Reading or .15°C for 2 years
Inputs	1 x 2-, 3-, and 4-wire RTDs, thermocouple, millivolt, ohm
Supply Voltage	9 - 32V in Profibus PA Protocol
Form Factor	DIN A Head Mount
