ps Printing Plate

Name: ps Printing Plate
Brand: huanyu
SKU: 101438019

US$ 1 - 5 MOQ: 1000 Square Meters

Key Specifications

Use:

Offset Printing

Material:

Aluminum

Style:

Positive

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai China(mainland)

Delivery Detail:

Delivery time depends on order quantity.

Use Offset Printing

Material Aluminum

Style Positive

Type PS Plate

Place of Origin Shanghai, China

Brand Name huanyu

Model Number PS-101

Specifications

Use :Offset Printing
Material :Aluminum
Style :Positive
Type :PS Plate
sizes :0.15mm to 0.30mm

Plate:

Features Specifications: positive ps plate/ps offset printing plates

Plate Type	Conventional Posititve
Substrate	Electromechanically Grained and Anodized Lithographic Aluminium.
Alloy	Standard 1050 Alloy.
Gauge Available	0.15, 0.20,0.25, 0.27,0.40(mm)
Maximum Width	1,450mm
Handling	Plates are light sensitive. Handle under yellow safelight (uv free) until processed.
Colour Change	Blue Green to Pale Green
Light Source and Exposure	Automatic plate maker is recommendable. Light source: Iodine-Gallium lamp/Metal halide lamp. Exposure Condition - Step tablet: 3 step clear, Power of Light: 4 kw, Time: 30-50 seconds.
	1 meter distance between plate and lamp.
Process	Conventional
Developer	Flying positive developer of universal positive developer is recommended. Dilution - 1 (developer) : 12 (water).
Recommended Developer Temperature	18 - 22°C by hand, 20 - 23°C by machine
Development Time	30 - 40 seconds
Deletion	Conventional Pens
Shelf Life	18 - 24 months when stored in a dark, cool and dry space.
Recommended Processing	Automatic plate processor is recommended.
Length of Run	80,000-100,000 copies of impression. Depends upon printing condition like press, ink, paper and so on.
Plate Cleaner Compatibility	Universal Plate Cleaner is recommended.
