China Supplier Conveyor Manufacturer Lifting Hoist Equipment
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
China Supplier Conveyor Manufacturer Mini Electric Hoist 100Kg
-
China Supplier Conveyor Manufacturer Cheap Electric Hoist Machine
-
China Supplier Conveyor Manufacturer Cheap Price Hoist Conveyor
-
2014 New Condition Conveying Machine Large Capacity Food Grade Bucket Elevator
-
2014 New Condition Conveying Machine Large Capacity Bucket Elevator For Cement Plant
-
Conveying Machine Large Capacity Sand Bucket Elevators
Product Details
| Place of Origin | Henan, China | Brand Name | JINZHEN | |
| Model Number | JZHL; JZTH |
Product Description
Specifications
Lifting Hoist Equipment1.Large capacity
2.Professional design
3.Easy operation&Strong structure
4.CE, ISO9001
Alibaba China Supplier Conveyor Manufacturer Lifting Hoist Equipment
Product introduction- Lifting Hoist Equipment
Bucket elevator is a kind of with a belt or chain for the traction mechanism of vertical lifting equipment. Canveying height is 30-80 meters. Bucket elevator application scope is extremely broad, it's suitable for many different industries. Small field area, hoisting height range, good sealing, reliable operation, high efficiency, low energy consumption characteristics.
Working principle- Lifting Hoist Equipment
The hopper material scooped up from the following storage, with the conveyor belt or chain ascend to the top, flip down after bypass the crown chakra, bucket elevator poured material into receiving groove.
Product parts- Lifting Hoist Equipment
1.Feed inlet 2.adjusting bolt 3.chain 4.bucket 5.Transmission platform 6.actuating device 7.transmission
8.The upper section 9.Outlet 10.The middle housing case 11.Footing fixing bolt 12.The lower section
Application- Lifting Hoist Equipment
1. Food industry: fodder, flour, rice, starch, sugar, salt, corn, etc.
2. Mining industry: coal, sand, mineral, limestone, gypsum, etc.
3. Building industry: stone, cement, clay, lime, concrete, soil, etc.
Technical parameters- Lifting Hoist Equipment
| Type | Capacity (m³/h) | Bunker parameter | The speed of Main shaft (r/min) | Particle size of material (mm) | Lifting height (m) | Power (Kw) | |||
| Volume(L) | Distance(mm) | Speed(r/min) | |||||||
| JZHL300 | S | 28 | 5.2 | 500 | 1.25 | 37.5 | 40 | 30.16 | 5.5-10 |
| Q | 16 | 4.4 | 500 | 1.25 | 37.5 | 40 | 30.16 | ||
| JZHL400 | S | 47.2 | 10.5 | 600 | 1.25 | 37.5 | 50 | 21.92 | 5.5-10 |
| Q | 30 | 10 | 600 | 1.25 | 37.5 | 50 | 30.32 | ||
| JZTH315 | zh | 35 | 3.75 | 512 | 1.4 | 42.5 | 45 | 50 | 4-11 |
| sh | 59 | 6.0 | 512 | 1.4 | 42.5 | 45 | 50 | ||
| JZTH400 | zh | 58 | 5.9 | 512 | 1.4 | 37.6 | 55 | 50 | 7.5-18 |
| sh | 94 | 9.5 | 512 | 1.4 | 37.6 | 55 | 50 | ||
| JZTH500 | zh | 73 | 9.3 | 688 | 1.5 | 35.8 | 65 | 45 | 11-22 |
| sh | 118 | 15 | 688 | 1.5 | 35.8 | 65 | 45 | ||
| JZTH630 | zh | 114 | 14.6 | 688 | 1.5 | 31.8 | 75 | 50 | 11-37 |
| sh | 185 | 23.6 | 688 | 1.5 | 31.8 | 75 | 50 | ||
JZTH: zh- Medium deep bucket, for clammy material, like sugar, wet sand.
sh- Deep bucket, for dry powder and grain, like cement, sand and coal.
JZHL: Q- Shallow round bottom bucket, for the material that wet, easy to caking, hard to throw, like wet sand, wet coal.
S- Deep round botton bucket, for the material that dry, loose and easy to throw, like cement, coal sheet, gravel.
Advantages- Lifting Hoist Equipment
1. Tough Chain structure and very strong hopper connection.
2. The abrasion of chain is small, Stronger than belt type.
3. Suitable for a large quantity of industries.
4. Large capacity, Reliably Sealing and High efficiency.
Producing process- Lifting Hoist Equipment
Certification- Lifting Hoist Equipment
CE,BV,ISO9001,Supplier Assessment,Letter of Patent,Quality Authentication
Packaging- Lifting Hoist Equipment
Fumigation-free wooden case.
Waterproof, anti-corrosion, difficult to burn, sturdy and durable
