CTP THERMAL PRINTING PLATE
- 800000000 Square Meter / Square Meters per Month
- shanghai China(mainland)
- T/T Credit Card
Product Details
Use: | Offset Printing | Material: | Aluminum | Style: | Positive |
Type: | CTP Plate | Place of Origin: | Shanghai, China | Brand Name: | huanyu |
Model Number: | CTP |
Product Description
Specifications
Advantages:1) high performance;
2) high resolution;
3) good reproduction;
4) stable quality;
Technical specifications | |
Plate Type | Positive working, no preheat thermal digital plate, with optional post bake for longer runs |
Application | Medium for sheet fed, web offset press |
Aluminum | Electrochemically grained and anodized aluminum substrate |
Gauge | 0.15/0.30mm |
Maximum short grain width | 1320mm |
Spectral sensitivity | 800 - 850nm |
Plate setter compatibility | All the main brands in market, like Kodak Trendsetter/Lotem /Magnus, Screen PT-R, Heidelberg Top setter/Supra setter etc. |
Laser energy required | 120 - 160 mJ/cm 2 (varies based on plate setter manufacturer and developing condition) |
Resolution | 1% to 99% @ 200 lpi. Dependent upon capability of imaging device. |
FM capability | 20 micron stochastic. |
Developer | HUI DA brand |
Processing | 23°degree/23-27 seconds, |
Run length | 100, 000 impressions unbaked, over 500, 000 impressions baked. Actual run length may vary according to press/paper/ink conditions |
Safelight | Daylight handling |
Shelf life | 12 months, under recommended storage conditions |
Transport and storage | Store plates flat in their packaging, away from excessive cold, heat or high humidity. |
Package | 0.15MM, 100 sheets/ box, 0.30mm 50sheets/ box |
Payment | L/C, T/T |
Price | FOB, CFR, CIF |
