Solar Low-E Glass is a kind of low iron glass with ultra clarity, its normal light transmittance is higher than 91%. With its high performances like stability and good processability, it’s specially used for solar photovoltaic ( PV) and photo-thermal products.
Features:
1. Excellent Optical Performances.
2. Good Processability.
3. Complete Product Series.
4. Continuous and Stable Supply.
5. Excellent Service: Supplying the endusers for utilizing solar energy with “made-to-order” production and “one-stop” procurement service from original glass sheet to further processing (Washing, Grinding, Tempering and Drilling) to comprehensively satisfy customer’s requirements.
6. Technical Parameters:
Optical Parameters:
Thickness |
(370nm-800nm) Visible Light Transmittance |
(370nm-800nm) Visible Light Reflectivity |
(400-1000nm) Solar Transmittance |
(400-2400nm) Solar Reflectivity |
(300nm-390nm) UV Transmittance |
3mm |
91.6 |
8.2% |
91.2% |
8% |
89.5% |
3.2mm |
91.5 |
8.2% |
91.1% |
8% |
89.5% |
4mm |
91.3 |
8.2% |
91.0% |
8% |
89.2% |
5mm |
91.2 |
8.2% |
90.8% |
8% |
88.5% |
Mechanical Parameters:
Elasticity Modulus |
73.1Gpa |
Rupture Modulus(Tensile Strength-ultimate) |
41.4Mpa |
Knoop Hardness |
456kgf/mm2 |
Physical Parameters:
Density |
2.5076g/cm2 |
20-300℃ Linear Coefficient of Expansion 20-300℃ |
9.28×10-6 / ℃ |
Linear Coefficient of Expansion 20-450℃ |
9.75×10-8 / ℃ |
Transformation Temperature |
556 ℃ |
Intenerate Temperature or Yield Point |
606℃ |
Softening Point |
710℃ |
Annealing Point |
547℃ |
Strain Point |
513℃ |
log2 High Temperature Viscosity log2 |
1392℃ |
log3 High Temperature Viscosity log3 |
1152℃ |
log4 High Temperature Viscosity log4 |
996℃ |
Liquid Phase Temperature |
1008℃ |
Specifications:
Thickness: 3mm, 3.2mm, 4mm and 5mm
Size: 3660*2440mm
3660*2134mm
customized sizes
Applications:
Solar Low-E Glass can be used in the following aspects:
1. Superstrate of Thin-film Solar Panels
With higher solar light transmittance, it can improve the photoelectric conversion efficiency of the solar cells.
2. Flat Solar Collectors
With higher visible light transmittance, it can improve the photo-thermal conversion efficiency of the solar collectors.
3. Solar Mirrors
Take full advantage of extremely high reflectivity of the ultra clear glass mirror to improve the thermal efficiency, thereby to enhance the overall efficiency of thermal power generation.
4. BIPV Project (Building Integrated Photovoltaic)
In the BIPV project, Solar Low-E Glass (and TCO glass) can be used for both front-panel glass and seal glass of the thin-film solar cell. In photoelectric curtain walls, Solar Low-E Glass can not only satisfy the requirements of indoor lighting but also help the photovoltaic efficacy of power generation, it will be the main development trend of future buildings.
5. Greenhouse Glass
Solar Low-E Glass can accelerate the plants’ photosynthesis and shorten the growth period, help clients gain more economical benefits.
